NMEA 2000 Connector

Antenna Control Unit (ACU):
1 2
5
4 3
NMEA 2000 Connector
(Male Connector Type)
Male
Pin Signal
1 Shield
NET-S,
2
(power supply positive, +V)
NET-C,
3
(power supply common, -V)
4 NET-H, (CAN-H)
5 NET-L, (CAN-L)

LAN 1~4 Ports

Antenna Control Unit (ACU):
LAN Ports
Pin Signal
1
Tx-
2
Tx+
3
Rx-
4
NC
5
NC
6
Rx+
7
NC
8
NC
Cable Connector
Sockets
Connector
Threads
Cable Connector
41
:
2 1
5
3 4
NMEA 2000 Connector
(Female Connector Type)
Female
:
LAN Ports
Installing ACU
Pins
Connector
Threads
1 2
5
4 3
Male
