Specification

Technical Specification

Antenna System
Antenna Radome Height
Antenna Radome Diameter
Antenna Reflector Diameter
Antenna Unit Weight (With Radome)
Platform
Positioning
Azimuth Range
Elevation Range
Cross-level Range
Stabilization Accuracy
Motor Brake System
Roll
Pitch
Ship's motion
Yaw
Turning rate
Frequency
RX
Gain
Frequency
Tx
Gain
G/T over Rx Range
at elevation angle > 30 deg.
Polarization
BUC
LNB
ACU to ADU Cable (Antenna Cable)
Input power
1229 mm (48.38")
Ø1131mm (44.52")
Ø850 mm (33.46")
96 kg (211.6 Ibs)
3-axis: Azimuth, Elevation, Cross-level
3-axis Velocity Mode Servo Control:
Azimuth, Elevation, Cross-Level
Unlimited
-20° to +115°
Up to ± 37º
0.2° peak mispointing @ max ship motion condition
Dynamic braking
± 25° at 6 second
± 15° at 6 second
± 8° at 6 second
Up to 12°/sec & 5°/sec2
10.7 ~ 12.75 GHz
38.9 dBi @ 11.7GHz (without radome)
13.75 ~ 14.5 GHz
40.7 dBi @ 14.25GHz (without radome)
> 18.3 dB/K @ 12.75GHz (with radome)
Linear Polarization (Co & Cross-pol)
NJRC 8W (standard), 16W/25W (optional)
Intellian PLL LNB
Single 50-ohm coax cable for Rx, Tx, FSK, Reference and Power
from ACU to ADU
48VDC (max 300W) through Rx/Tx RF Cable
102
