Fuji Electric Model: PXR4 Instruction Manual page 20

Please see the table as shown below.
O: Possible combination
X: Impossible combination
Note 1) The alarm is not turned on the first time the measured value is in the
Cautions on alarms
No.
1 Note that the ON delay function is effective for alarm in error status.
2 Even during "Err" display, alarms in error status work.
3 Even when "LLLL" or "UUUU" is displayed, an alarm function works normally.
4 Alarm action type codes in No.12 to 15 are also included in No.24 to 27.
It is, therefore, recommended to use No.24 to 27. In addition, please note
when selecting No.12 to 15, setting in ALM2, dLY2, and A2hy are effective.
5 With the HB alarm, ON delay function, de-energizing function and latch
function cannot be used.
6
The minimum alarm set value is –199.9.
7 As the alarm action type changed, the alarm set value may also be
changed accordingly.
8 Note that all of alarm outputs are not provided at the standby condition.
9
Error status alarm is not provided at the standby mode.
10 The HOLD function is effective even if the PV value is in the hysteresis area
when the power is turned ON.
Combination of alarm functions
Without HOLD/Timer
Alarm latch
De-energizing
ON delay
Alarm in error status
alarm band. Instead it turns on only when the measured value goes out
of the band and enters it again.
Cautions
– 20 –
With HOLD
O O
O O
O Note 1
O O
With Timer
X
O
X
X
Items/Classification
Alarm in error
status
Alarm at error
indication
Alarm action type
code
HB alarm
Alarm set value
Alarm at standby
mode.
