4

Display and operation

Standby mode
· To perform standby operation, set "STby" as ON in the
1st block parameter.
C1 C2 AL1 AL2 AL3
PV
SV
SEL
PXR-4
Operation mode
C1 C2 AL1 AL2 AL3
PV
SV
SEL
PXR-4
Parameter setting mode
Press the SEL
3
Shift to operating condition
Parameter setting procedure
1 Select a parameter you want to
set by pressing the or
key.
2-1 Press the key to allow the
SEL
parameter to change.
(Under the changing condition,
the parameter set value flickers).
2-2
Pressing the or key, to
change the parameter set value.
2-3
After the parameter has been
changed, press the key
SEL
for registration.
3 To shift to Operation/Standby
mode, press the key for 2 sec.
SEL
· Standby mode:
(Output) Control outputs (1 and 2) and alarm outputs (all) are not provided. However,
depending on setting of "P-n1", control action, control outputs are provided at the
abnormal input.
No alarm output is provided at standby mode, even in (Fault-condition).
Caution
Be careful since the equipment does not provide output of the alarm of
the main unit abnormality during the standby operation.
(Control) Control is not performed.
(Display) SV display flickers.
Caution The SV display does not flicker while the 1st, 2nd and
3rd block parameters are displayed.
(Setting) SV and parameter settings are able to perform.
1
Change of set value (SV)
When the SV lamp is lit, the set value (SV) is displayed at the lower line.
The set value (SV) can be changed.
Caution After the data setting, the data are registered
automatically in 3 seconds.
2
Shift to the 1st, 2nd and 3rd block parameter
To shift to the other blocks, press the
Caution
Depending on the pressing time of
you can select the block to shift.
pressing time
SEL
About 1 sec pressing
About 3 sec pressing
About 5 sec pressing
1
Parameter selection
for 2 sec.
C1 C2 AL1 AL2
Operation mode PV
SV
SEL
PXR-4
Parameter search.
Press the .
C1 C2 AL1 AL2
PV
SV
SEL
PXR-4
SEL key.
SEL key,
Shifting block
1st block
2st block
3st block
2
Parameter settings
AL3 C1 C2
PV
Press the
SEL once.
SV
SEL
PXR-4
Press the .
SEL
AL3
Registers parameter set value, returning
to the parameter shift mode
By repeating the same procedure, the parameters
can be displayed according to the parameter list
shown in 5, Setting methods of temperature and
parameters.
– 11 –
Switching by 1st block
STby settings
Switching by the
AL1 AL2 AL3
Parameter change.
Increases parameter set value
Decreases parameter set value
.
1
SEL key
