1St Block Parameter - Fuji Electric Model: PXR4 Instruction Manual

5
Setting methods of temperature and paramenters
Operation/Standby mode
Alarm status
Control output status
PV value
indication
SV value
indication
Press for about 1 sec.

1st block parameter

Parameter
display symbol
STbY
ProG
LACH
AT
TM-1
TM-2
AL1
A1-L
A1-H
AL2
A2-L
A2-H
LoC
Note 1)
Note 2) Never set "TC" / "TC2" = 0
· Some parameters may not be displayed on the screen, depending upon the types.
Operation
C1 C2 AL1 AL2
PV
SV
SEL
PXR-4
When the set value (SV) is displayed at the lower line, the SV lamp is lit.
SEL
Parameter
Switches RUN or Standby of the control.
Standby settings
ON: Control standby (output: OFF, alarm: OFF)
OFF: Control RUN
Ramp/soak control
OFF: stop, rUn: Start, HLd: status hold
Alarm latch cancel Releases alarm latch.
1: Alarm latch release
Auto-tuning 0: Stop, 1: Standard AT start, 2: Low PV type AT start
Timer 1 display
Time displays remining time at the timer mode.
Timer 2 display
Alarm 1 set value (appears only with alarm action type 1 to 10).
Setting range: Note 1
Alarm 1 low limit (appears only with alarm action type 16 to 31).
Setting range: Note 1
set value
Alarm 1 high limit (appears only with alarm action type 16 to 31).
set value Setting range: Note 1
Alarm 2 set value (appears only with alarm action type 1 to 10).
Setting range: Note 1
Alarm 2 low limit (appears only with alarm action type 16 to 31).
set value Setting range: Note 1
Alarm 2 high limit (appears only with alarm action type 16 to 31).
set value Setting range: Note 1
Key lock Setting of key lock status.
All parameters
Front key
0
1
2
3
4
5
Setting range : 0 to 100%FS (in case of absolute value alarm)
100 to 100%FS (in case of deviation alarm)
Standby
C1 C2 AL1 AL2 AL3
PV
AL3
SV
SEL
PXR-4
SEL
Description of contents
SV
Comm- Front key Comm-
unication unication
: Setting enable,
– 12 –
SV value
indication
flickers.
Press for about 2 sec.
Default
Remarks
setting
OFF
OFF
0
0
10
10
10 Table 3
(Page 4)
Table 3
10
(Page 4)
10 Table 3
(Page 4)
Table 3
10
(Page 4)
Table 3
10
(Page 4)
10 Table 3
(Page 4)
0
: Setting disable
