Operation/Standby mode
Alarm status
Control output status
C1
PV value
indication
PV
SV value
indication
SV
PXR-4
When the set value (SV) is displayed at the lower line, the SV lamp is lit.
Press for about 5 sec.
3rd block parameter
Parameter
Parameter
display symbol
P-n1
Control action
Lower limit of SV
SV-L
SV-H
Upper limit of SV
dLY1
ON delay time of
alarm 1
ON delay time of
dLY2
alarm 2
CT
CT input value
Hb
HB alarm set value
A1hY
Hysteresis for
alarm 1
Hysteresis for
A2hY
alarm 2
A1oP
Additional function
of alarm 1
Additional function
A2oP
of alarm 2
DI1 function
dl-1
STno
Station No.
CoM
Parity setting
PYP
Code for PYP input
type
dSP1
Parameter mask
to
dSP13
Note 3) De-energized: Contact opens when the alarm "ON".
Standby
Operation
C1
C2
AL1
PV
C2
AL1
AL2
AL3
SV
SEL
PXR-4
SEL
SEL
Description of contents
Selects the control action.
Lower limit of SV
(Setting range: 0 to 100%FS)
Upper limit of SV
(Setting range: 0 to 100%FS)
ON delay time setting for alarm output
(Setting range: 0 to 9999 sec)
CT (Current Transformer) input value
Sets current value to detect the heater disconnection
(Setting range: 1.0 to 50.0A, 0: OFF)
Sets ON-OFF hysteresis for alarm output.
(Setting range: 0 to 50%FS)
Additional function of alarm output
(Setting range: 000 to 111)
Alarm latch (1:use, 0:not use)
Alarm of error status (1:use 0:not use)
De-energized (1:use 0:not use), Note 3.
Selects digital input 1 (DI1) function
(Setting range: 0 to 12)
Communication station No. (Setting range: 0 to 255)
Parity setting. Baud rate is fixed at 9600 bps.
(Setting range: 0 to 2)
Input type code used when communicating with PYP.
See the OPERATION MANUAL
(Initial value: K: 0 to 400 C)
Specifying parameter mask
– 14 –
AL2
AL3
SV value
indication
flickers.
SEL
Press for about 2 sec.
Default
setting
0
0%FS
100%FS
0
0
-
0.0
1
1
000
000
0(OFF)
1
0
34
Remarks
Table 4
(Page 4)
6-7
(Page 3)
6-6
(Page 3)
