Check of specifications and accessories
Before using the controller, check if the type and specifications are as ordered. (A Table of Model code configu-
ration is given in Page 4).
Check that all of the following accessories are included in the package box.
· Temperature controller
· Instruction manual
· Mounting bracket
· I/V unit (250Ω resistor)
· Terminal cover
The related documents
For details, refer to the following documents.
Contents
Specifications
Operation method
Communication functions
1 unit
1 copy
1 pce.
1 pce. (4-20mA DC input type only)
1 pce. (optional item seperately ordered.)
Name
Catalogue
MICRO-CONTROLLER X (Model : PXR)
OPERATION MANUAL
COMMUNICATION FUNCTIONS (MODBUS)
INSTRUCTION MANUAL
– 2 –
Name
ECNO : 1136
ECNO : 406
INP-TN512642-E
