Analog Output Option Replaceable Parts
Table 8. Analog Output Option Replaceable Parts
Description
Analog output board assembly
Analog link cable
Analog trunk cable
Output connector box
assembly
Output connector box power
module
Power Module Mount
Power Module Mount "L"
Bracket
Analog output cable, non-
plenum, 15.2 m or 50ft.
Analog output cable, non-
plenum, 30.5 m or 100ft.
Analog output cable, non-
plenum, 76.2 m or 250ft.
Analog output cable, non-
plenum, 152.4 m or 500ft.
Analog output cable, plenum,
15.2 m or 50ft.
Analog output cable, plenum,
30.5 m or 100ft.
Analog output cable, plenum,
76.2 m or 250ft.
Analog output cable, plenum,
152.4 m or 500ft.
Bedside monitor cable, 3-wire,
8-pin
Bedside monitor cable, 3-wire,
12-pin
50
Exchange
Part No.
M2604-68021
New
Part No.
M2604-60021
M1401-60751
M1401-60752
M2604-60961
M2600-60008
M1407-00070
M1407-00040
M1401-60761
M1401-60762
M1401-60763
M1401-60764
M1401-60765
M1401-60766
M1401-60767
M1401-60768
M1401-60753
M1401-60754
