Frequent Dropouts and NO SIGNAL, WEAK
SIGNAL, and TEL CANNOT ANALYZE INOPs on a
Single Channel
Frequent Dropouts and NO SIGNAL, WEAK
SIGNAL, and TEL CANNOT ANALYZE INOPs with
Multiple Channels
Frequent Dropouts along with TEL CANNOT
ANALYZE and INTERFERENCE INOPs
Transmitter Torque Requirements
If the transmitter is disassembled, certain screws must be
re-installed at specific torque specifications. Figure 2
shows the torque requirements in the transmitter.
Conversion Chart
2 inch-pounds = 0.23 joules
3 inch-pounds = 0.34 joules
6 inch-pounds = 0.68 joules
6 inch-
pounds
4
Message
Figure 2 Torque Requirements
3 inch-
pounds
3 inch-
pounds
Troubleshooting Overview
Page
25
29
30
2 inch-
pounds
