2. Make certain that the light source and photo
detector are opposite each other and that the light
passes through the ateriolar bed.
3. Reposition the transducer to a site with higher
perfusion.
4. Replace the transducer.
5. Replace the adapter cable.
SpO INTERFERENCE INOP
2
This INOP can be caused if the level of ambient light is so
high that the SpO
pulse rate. It can also be caused by an equipment
malfunction. If this INOP appears, do the following.
1. Cover the transducer with a non-white opaque
material (e.g., pulse oximeter probe wraps - Posey
wrap or equivalent). If it does not solve the
problem, continue.
2. Replace the transducer.
3. Replace the adapter cable.
4. This problem can also be caused by electrical
interference. Reduce or remove any sources of
electrical interference.
SpO NO TRANSDUCER INOP
2
This INOP can occur if the SpO
disconnected, dirty, or broken. It can also be caused by a
transmitter failure. If this INOP appears, do the following.
1. If the transducer is disconnected, reconnect the
transducer.
2. Replace the transducer.
3. Replace the SpO
Transmitter SpO2 Problems
transducer cannot measure SpO
2
Board.
2
transducer is
2
or
2
13
