Lockly SECURE Installation Manual page 8

STEP 5: INSTALLING THE EXTERIOR ASSEMBLY
A
EXTERIOR VIEW
Center Hole
Side Hole
B
INTERIOR VIEW
Route cable through center hole, then push it into side hole.
Note:
Please use rotate the
torque blade into the vertical
position for installation.
A. When the bolt is extended,
the torque blade should be kept
in a vertical position.
B. Make sure the cable goes
underneath the latch.
