Lockly SECURE Installation Manual page 14

O Screw
*Secure top with M1 or M2
O Screw
6.3
Pull the cable from the exterior
lock through the rectangular
hole underneath the positioning
rods and square rod.
Secure the hole above the
square rod with Part O screw.
6.4
Remove the position rods (Part V)
and replace them with Part O
screws. Tighten clockwise until the
mounting plate is secure.
* If you have drilled a hole on the
top in Step 1, please secure the
hole with part M1 or M2 depending
on your door thickness. Skip this if
no hole was drilled in Step 1.
M1
PM5X25mm
M2 PM5X35mm
