PNA-L RF Interface Cable Connections (U3021-60045)
PNA-L RF Interface Cable Connections (U3021-60045)
Figure 16 on page 20
illustrates the cable configuration of the test set to the analyzer. The cables have
been supplied with Cable Kit (U3021-60045).
1. Remove the SOURCE OUT to CPLR THRU and RCVR IN to CPLR ARM jumpers (x16) on the analyzer. The
RCVR R1-R4 to SOURCE OUT reference loop jumpers (x1) remain on the front panel.
2. Connect the RF interconnect cables, supplied with this option, from the analyzer to the test set. As you
are connecting each cable, torque to 8 in-lb.The Z5623-20418 is the short cable and the Z5623-20419
is the long cable.
Table 8
Over torque will cause damage to the test set and may cause connectors to spin or become
loose.
Each end of the interconnect RF cables have a different length from the bend. When
connecting the RF Interconnect cables be sure that the longer end from the bend is
connected to the PNA-L.
Table 8
PNA-L Interface Cable Connection (U3021-60045)
RF Cables
From: PNA-L
Z5623-20418
SOURCE OUT
Z5623-20418
CPLR ARM
Z5623-20419
CPLR THRU
Z5623-20419
RCVR IN
and
Figure 16 on page
20.
To: Test Set
SOURCE OUT
CPLR ARM
CPLR THRU
RCVR OUT
19
