COM-880E
COM Express Basic Type 6 CPU Module
CPU
Intel ® Core™ i7-3517UE
processor
LAN
Intel ® 82579LM Gigabit
Ethernet
- 1 -
Wide Range Temperature
Quick Installation Guide
Chipset
Intel ® QM77
Audio
HD Audio Interface
Version 1.1
4046770200110P
Advertisement
Table of Contents
Related Manuals for Arbor Technology COM-880E
Summary of Contents for Arbor Technology COM-880E
-
Page 1: Technical Support
COM-880E Wide Range Temperature COM Express Basic Type 6 CPU Module Quick Installation Guide Version 1.1 Form Factor Chipset Intel ® Core™ i7-3517UE Intel ® QM77 COM Express Type 6 CPU Module processor Video Audio Intel ® 82579LM Gigabit 24-bit Dual Channels... -
Page 2: Packing List
Module Type 2, 3, 4, 5 and 6 support two connectors with four rows of pins (440 pins) Connector placement and most mounting holes have transparency between Form Factors. The differences among the Module Type 6 and COM-880E are summarized in table below: Module Type... -
Page 3: Specifications
Specifications COM Express Basic Type 6 CPU Module Form Factor ® Intel Core™ i7-3517UE 1.7GHz processor Intel PCH QM77 Chipset ® 2 x DDR3 SO-DIMM sockets, supporting SDRAM up System Memory to 16GB Intel Graphics Media Accelerator 4000 graphics ® VGA/ LCD core w/ Analog RGB (resolution up to 2560 x 1600)/ Controller... -
Page 4: Ordering Information
Ordering Information Intel i7-3517UE/ QM77 WT COM Express CPU ® COM-880E-3517UE module Optional Accessories HS-65M2-F2 Heat Spreader (95 x 95 x 11mm) Universal evaluation heatsink kit w/ thermal HS-0000-W4 pad (dimension: 125x95x22mm, only used on a flat type heatspreader) COM Express type 6 evaluation carrier board... - Page 5 Windows 7 CHIPSET \CHIPSET \Graphic\32\Win7_Win8 \Graphic\64\Win7_Win8 \Ethernet\32\Win7_WIN8 \Ethernet\64\WIN7_WIN8 \Audio\win7_win8\32 Audio \Audio\win7_win8\64 Management \ME_8.0.20.1513 Engine \RST_AHCI_RAID\Win7_Win8 \RST_AHCI_RAID\32\Intel_RST_F6_floppy_Install- RAID er_Win7_Win8_v11.6.0.1030 \RST_AHCI_RAID\64\Intel_RST_F6_floppy_Install- er_Win7_Win8_64_v11.6.0.1030 Intel Turbo \Turbo Boost USB3.0 \USB3.0 Windows 8 CHIPSET \CHIPSET \Graphic\32\Win7_Win8 \Graphic\64\Win7_Win8 \Ethernet\32\Win7_WIN8 \Ethernet\64\WIN7_WIN8 \Audio\win7_win8\32 Audio \Audio\win7_win8\64 Management \ME_8.0.20.1513 Engine \RST_AHCI_RAID\Win7_Win8 \RST_AHCI_RAID\32\Intel_RST_F6_floppy_Install- RAID...
-
Page 6: Connectors Quick Reference
Connectors Quick Reference Top side Bridge Processor QM77 Bottom side COM Express AB Connector COM Express CD Connector COM Express CD Connector COM Express AB Connector - 6 -... -
Page 7: Board Dimensions
Board Dimensions 71,58 30,00 4,00 Bridge Processor QM77 76,00 41,00 4,00 55,68 86,01 125,00 45,35 Ø2.6*Ø6.5 Unit: mm - 7 -... - Page 8 COM Express AB Connector (bottom side) GND (FIXED) GND (FIXED) PCIE_RX4- PCIE_TX4- GBE0_ACT# GBE0_MDI3- GPO2 LPC_FRAME# GBE0_MDI3+ PCIE_RX3+ PCIE_TX3+ LPC_AD0 GBE0_LINK100# PCIE_TX3- PCIE_RX3- LPC_AD1 GBE0_LINK1000# LPC_AD2 GBE0_MDI2- PCIE_RX2+ PCIE_TX2+ LPC_AD3 GBE0_MDI2+ PCIE_RX2- PCIE_TX2- LPC_DRQ0# GPO3 GPI1 LPC_DRQ1# GBE0_MDI1- PCIE_RX1+ PCIE_TX1+ GBE0_MDI1+ LPC_CLK PCIE_RX1-...
- Page 9 COM Express CD Connector COM Express CD Connector (bottom side) GND (FIXED) GND (FIXED) PEG_TX1- PEG_RX1- TYPE2# TYPE1# USB_SSTX0- USB_SSRX0- PEG_TX2+ PEG_RX2+ USB_SSTX0+ USB_SSRX0+ PEG_TX2- PEG_RX2- GND (FIXED) GND (FIXED) USB_SSTX1- USB_SSRX1- PEG_TX3+ PEG_RX3+ USB_SSRX1+ PEG_RX3- USB_SSTX1+ PEG_TX3- RSVD RSVD USB_SSRX2- RSVD USB_SSTX2-...
- Page 10 This page is intentionally left blank. - 10 -...
