- Page 1 EmQ-i230J Qseven® CPU Module User’s Manual Version 1.0 2020.06...
- Page 2 This page is intentionally left blank. - II -...
- Page 3 Revision History Version Release Time Description 2020.06 Initial release - i -...
-
Page 4: Table Of Contents
Contents Contents Revision History .................i Contents .....................ii Preface....................iv Copyright Notice ..................iv Declaration of Conformity ..............iv CE ....................iv FCC Class A ..................v RoHS ....................v SVHC / REACH ................vi Warning ....................vi Replacing the Lithium Battery ..............vi Technical Support .................. -
Page 5: Contents
Contents 3.2.12. SIO FINTEK81866D ............23 3.3. Security ..................24 3.4. Power ..................... 25 3.5. Boot ....................26 3.6. Exit ....................28 - iii -... -
Page 6: Preface
Preface Preface Copyright Notice All Rights Reserved. The information in this document is subject to change without prior notice in order to improve the reliability, design and function. It does not represent a commitment on the part of the manufacturer. Under no circumstances will the manufacturer be liable for any direct, indirect, special, incidental, or consequential damages arising from the use or inability to use the product or documentation, even if advised of the possibility of such... -
Page 7: Fcc Class A
RoHS ARBOR Technology Corp. certifies that all components in its products are in compliance and conform to the European Union’s Restriction of Use of Haz- ardous Substances in Electrical and Electronic Equipment (RoHS) Directive 2002/95/EC. -
Page 8: Svhc / Reach
Preface SVHC / REACH To minimize the environmental impact and take more responsibility to the earth we live, Arbor hereby confirms all products comply with the restriction of SVHC (Substances of Very High Concern) in (EC) 1907/2006 (REACH --Registration, Evaluation, Authorization, and Restriction of Chemicals) regulated by the European Union. -
Page 9: Warranty
Preface Warranty This product is warranted to be in good working order for a period of two years from the date of purchase. Should this product fail to be in good working order at any time during this period, we will, at our option, replace or repair it at no additional charge except as set forth in the following terms. - Page 10 This page is intentionally left blank. - viii -...
-
Page 11: Chapter 1 Introduction
Chapter 1 Introduction Chapter 1 - Introduction - 1 -... -
Page 12: Features
Introduction 1.1. Features • Fanless Design ® • Soldered Onboard Intel Atom™ Processor E3800 family • Integrated Gigabit Ethernet • Soldered Onboard eMMC(OEM Request) • Dual Channels 24-bit LVDS, DDI Port • Wide Range Operating Temp.: -40 ~ 85ºC 1.2. About this Manual This manual is intended for experienced users and integrators with hardware knowledge of computers. -
Page 13: Specifications
Introduction 1.3. Specifications Form Factor Qseven CPU Module ® Soldered onboard Intel® Atom™ Processor E3800 family Processor E3825 1.33GHz or E3845 1.91GHz Memory Soldered onboard 2GB/4GB DDR3L SDRAM BIOS Insyde BIOS Watchdog 1~255 levels reset USB 2.0 8 x USB 2.0 ports Expansion 3 x PCIex1, I2C,SDIO 2 x Serial ATA ports with 300MB/s HDD transfer rate... -
Page 14: Inside The Package
Introduction 1.4. Inside the Package Before starting with the installation, make sure the following items are shipped. If any of the items is missing or appears damaged, contact your local dealer or distributor. 1 x EmQ-i230J Qseven® CPU Module 1 x Quick Installation Guide - 4 -... -
Page 15: Ordering Information
Introduction 1.5. Ordering Information Intel Atom™ Processor E3825 Qseven CPU module with 2GB ® ® EmQ-i230J-WT-E3825-2G memory soldered on module Intel Atom™ Processor E3845 Qseven CPU module with 2GB ® ® EmQ-i230J-WT-E3845-2G memory soldered on module Intel Atom™ Processor E3825 Qseven CPU module with 4GB ®... -
Page 16: Driver(7.1A) Installation Note
Introduction 1.7. Driver(7.1A) Installation Note To install the drivers, please visit our website at www.arbor-technology. com and download the driver pack from the product page. Windows 7 Driver Path \EmQ-i230J\Win7\Audio\32bit_Win7_R273 Audio \EmQ-i230J\Win7\Audio\64bit_Win7_R273 Chipset \EmQ-i230J\Win7\Chipset \EmQ-i230J\Win7\LAN\PROWin32 Ethernet \EmQ-i230J\Win7\LAN\PROWinx64 \EmQ-i230J\Win7\Graphic\32bit Graphics \EmQ-i230J\Win7\Graphic\64bit Processor \EmQ-i230J\Win7\Processor IO\Win7_IO_Drivers TXE Patch... -
Page 17: Chapter 2 Board Overview
Chapter 2 Board Overview Chapter 2 - Board Overview - 7 -... -
Page 18: Board Dimensions
Board Overview 2.1. Board Dimensions 35,9 Φ2,7* Φ6.35 Unit:mm - 8 -... -
Page 19: Block Diagram
Board Overview 2.2. Block Diagram DDR3L-1066/1333 MT/s Onboard DDR3L 2GB/4GB 1 x eDP port Dual Channels 24-bit LVDS PTN3460 Analog R.G.B. 1 x DDI port (DDI1) 3 x USB 2.0 ports 5 x USB 2.0 Ports 1 x USB 2.0 GL845G Intel ®... - Page 20 Board Overview Heat Spreader Installation To install the heat spreader: See the illustration below. Mount the heat spreader to the board. Fix the heat spreader in place with fours screws. - 10 -...
-
Page 21: Connector Pin Definition
Board Overview 2.3. Connector Pin Definition Pin Signal Pin Signal Pin Signal Pin Signal SDATA_IN0 I2C_CLK GBE_MDI3- GBE_MDI2- SDATA_OUT I2C_DAT GBE_MDI3+ GBE_MDI2+ THRM# WDTRIG# THRM_ALERT# WDOUT (N/C) GBE_LINK100# GBE_LINK1000# GBE_MDI1- GBE_MDI0- USB_P7- USB_P6- GBE_MDI1+ GBE_MDI0+ USB_P7+ USB_P6+ GBE_LINK# GBE_ACT# OVCUR#_C2 OVCUR#_C1 GBE_V1P5 SUS_S4#... - Page 22 Board Overview Pin Signal Pin Signal Pin Signal Pin Signal DP1_TX3_P SDVO_INT+ (N/C) DP1_TX3_N SDVO_INT- (N/C) SPI_MOSI SPI_CS0# SPI_MISO SPI_CS1# (N/C) DP1_TX1_P DPI0_AUXP SPI_SCLK CRT_RED DP1_TX1_N DPI0_AUXN VCC_5V_SB VCC_5V_SB CRT_VSYNC CRT_GREEN DP1_TX2_P SDVO_TVCLKIN+ (N/C) CRT_HSYNC CRT_BLUE DP1_TX2_N SDVO_TVCLKIN- (N/C) DP1_TX0_P DDI0_DDCDATA DP1_TX0_N DDI0_DDCCLK...
-
Page 23: Chapter 3 - Bios
Chapter 3 BIOS Chapter 3 - BIOS - 13 -... - Page 24 BIOS The BIOS Setup utility is featured by Insyde BIOS to configure the system settings stored in the system’s BIOS ROM. Insyde BIOS is activated once the computer powers on. After entering the utility, use the left/right arrow keys to navigate between the top menus and use the down arrow key to access one.
-
Page 25: Main
BIOS 3.1. Main The Main menu displays some BIOS info and features the settings of System Date and System Time. InsydeH20 Setup Utility Rev. 5.0 Advanced Security Power Boot Exit Main Set the current default language BIOS Version R1.07 used by the InsydeH2O. Project Name EmQ-i230J-WT Build Date... -
Page 26: Advanced
BIOS 3.2. Advanced The Advanced menu controls the system’s CPU, IDE, Super IO, AHCI and USB. It also helps users monitor hardware health. InsydeH20 Setup Utility Rev. 5.0 Advanced Security Power Boot Exit Main Configures Boot Settings. Boot Configuration PCI Express Configuration USB Configuration Audio Configuration LPSS &... -
Page 27: Boot Configuration
BIOS 3.2.1. Boot Configuration Setting Description Numlock Select Power-on state for Num lock 3.2.2. PCI Express Configuration Setting Description PCI Express Root Port Enables (default) /disables this PCIe port. PCIe Port Speed PCI Express Root Options are: Auto (default), Gen 1, Gen 2 Port 1/2/3 PCIe Port ASPM Options are:... -
Page 28: Audio Configuration
BIOS 3.2.4. Audio Configuration Setting Description Control detection of the Azalia device. Disabled: Azalia will be unconditionally disabled. Audio Controller Enabled (default): Azalia will be unconditionally enabled. Auto: Azalia will be enabled if present, disabled otherwise. 3.2.5. LPSS & SCC Configuration Setting Description LPSS &... -
Page 29: Security Configuration
BIOS 3.2.7. Security Configuration This page shows the TXE related information, including TXE Configuration , TXE FW Version, TXE FW Capabilities, TXE FW Features, TXE FW OEM Tag and TXE Firmware Mode. 3.2.8. Video Configuration 3.2.8.1 Video Configuration Setting Description Set Logo &... - Page 30 BIOS 3.2.8.3 PTN3460 (eDP to LVDS) Configuration Setting Description Set the Output Format of PTN3460. PTN3460 Output Options are (00) VESA (24bpp) / (01) VESA or JEIDA (18bpp) (default) Format / (10) JEIDA (24bpp) PTN3460 Channel Set the Channel mode of PTN3460. Control Options are Single (default) / Dual.
- Page 31 BIOS Set the size of DVMT 5.0 used by IGD IGD-DVMT total Gfx Mem Default: 256M Enables/disables IGD Turbo IGD Turbo Default: Auto IGD Thermal Enables/disables (default) IGD Thermal Spread Spectrum clock Enables/disables (default) Spread Spectrum clock 3.2.8.6 IGD- LCD Control Setting Description Set mode of as the Primary Display.
-
Page 32: Sata Configuration
BIOS 3.2.9. SATA Configuration Setting Description SATA Controller Enables (default) /disables the present SATA controller. SATA Test Mode Enables/disables (default) the SATA test mode. Select SATA Speed SATA Speed Options: Gen1 / Gen 2 (default) Configures how to sun the SATA drives. Chipset SATA Mode Options available are AHCI (default) and IDE. -
Page 33: Sio Fintek81866D
BIOS 3.2.12. SIO FINTEK81866D Setting Description Set the state of Power Loss mode Power Loss mode Options are Always On(default)/Always Off Serial Port Enables (default) /disables the Serial port. Base I/O Address Serial Port A, B, C, D Setup the Base I/O Address of the Serial Port. Interrupt Setup the Interrupt of the Serial Port - 23 -... -
Page 34: Security
BIOS 3.3. Security The Security menu sets up the password for the system’s administrator account. Once the administrator password is set up, this BIOS Setup utility is limited to access and will ask for the password each time any access is attempted. InsydeH20 Setup Utility Rev. -
Page 35: Power
BIOS 3.4. Power The Power menu sets up the power option of system InsydeH20 Setup Utility Rev. 5.0 Advanced Security Power Boot Exit Main These items control various CPU Advanced CPU Control parameters. S5 Wake on RTC <Disabled> Help Select Item F5/F6 Change Values Setup Defaults... -
Page 36: Boot
BIOS 3.5. Boot The Boot menu configures how to boot up the system such as the configuration of boot device priority. InsydeH20 Setup Utility Rev. 5.0 Advanced Security Power Boot Exit Main Select boot type to Dual type, Boot Type <Legacy Boot Type>... - Page 37 BIOS Select boot to Acpi 3.0/Acpi 1.0B APCI Selection Options are Acpi 1.0B / Acpi 3.0 / Acpi 4.0 (default) / Acpi 5.0 Disables or enables booting to USB boot devices. USB Boot Default: Enabled Set the waiting seconds before booting the default boot selection Timeout Default: 0 Enables/disables the Automatic Failover.
-
Page 38: Exit
BIOS 3.6. Exit The Save & Exit menu features a handful of commands to launch actions from the BIOS Setup utility regarding saving changes, quitting the utility and recovering defaults. InsydeH20 Setup Utility Rev. 5.0 Advanced Security Power Boot Exit Main Exit Saving Changes Exit system setup and save... - Page 39 BIOS - 29 -...
- Page 40 BIOS - 30 -...
