Form Factor
Qseven
CPU Module
®
LAN
Intel® i210AT PCIe GbE
controller
♦ Technical Support
If you have any technical questions, please consult the user's manual first at:
https://www.arbor-technology.com
Please do not hesitate to e-mail to our customer service if you still can not find out
the answer:
E-mail: info@arbor.com.tw
Declaration of Conformity
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions : (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Copyright © 2019 All Rights Reserved.
EmQ-i2200
CPU
Intel® Celeron™ Processor
N3160
Audio
HD Link
- 1 -
Qseven
R2.0 CPU Module
®
Quick Installation Guide
Video
Dual-Channel 24-bit LVDS/
DisplayPort & HDMI
selectable port
I/O
USB2.0/ USB SuperSpeed/
SATA/ PCIex1/ SDIO/ I2C/
UART
Version 1.2
4041220000120P
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Arbor Technology EmQ-i2200
Summary of Contents for Arbor Technology EmQ-i2200
- Page 1 EmQ-i2200 Qseven R2.0 CPU Module ® Quick Installation Guide Version 1.2 Form Factor Video Qseven CPU Module Intel® Celeron™ Processor Dual-Channel 24-bit LVDS/ ® N3160 DisplayPort & HDMI selectable port Audio Intel® i210AT PCIe GbE USB2.0/ USB SuperSpeed/ HD Link...
-
Page 2: Packing List
Packing List Before starting with the installation, make sure the following items are shipped: 1 x EmQ-i2200 Qseven CPU Module ® 1 x Quick Installation Guide Ordering Information Intel Celeron N3160 Quad Core Qseven R2.0 CPU ® ® EmQ-i2200-N3160-4G Module w/4GB memory soldered on module... -
Page 3: Specifications
Specifications Form Factor Qseven CPU Module ® Soldered onboard Intel® Celeron Processor N3160 System Memory Soldered onboard 4GB DDR3L SDRAM HD Graphic 400 Graphics Chipset Integrated Intel ® Ethernet controller 1 x Intel i210AT PCIe GbE controller ® Audio HD Link BIOS AMI BIOS Serial Port... -
Page 4: Driver Installation
Driver Installation To install the drivers (6.5A), please visit our website at www.arbor-technology. com and download the driver pack from the product page. If you need login access, please contact your local ARBOR sales representative. - 4 -... -
Page 5: Board Dimensions
Board Dimensions 32,26 ø2,7 Unit:mm - 5 -... -
Page 6: Heat Spreader Installation
Heat Spreader Installation To install the heat spreader: See the illustration below. Mount the heat spreader to the board. Fix the heat spreader in place with fours screws. - 6 -... -
Page 7: Connector Pin Assignment
Connector Pin Assignment Pin Signal Pin Signal Pin Signal Pin Signal HDA_SDI I2C_CLK GBE_MDI3- GBE_MDI2- HDA_SDO I2C_DAT GBE_MDI3+ GBE_MDI2+ THRM# WDTRIG# THRMTRIP# WDOUT GBE_LINK100# GBE_LINK1000# GBE_MDI1- GBE_MDI0- USB_SSTX0- USB_SSRX0- GBE_MDI1+ GBE_MDI0+ USB_SSTX0+ USB_SSRX0- GBE_LINK# GBE_ACT# USB_6_7_OC# GBE_CTREF USB_4_5_OC# SUS_S5# (N/C) (N/C) USB_SSTX1- USB_SSRX1-... - Page 8 FAN_TACHOIN 129 CAN0_TX (N/C) 130 CAN0_RX (N/C) 196 FAN_PWMOUT (N/C) Pin Signal Pin Signal Pin Signal Pin Signal 131 DDI0_TX3+ 132 RSVD (N/C) 197 GND 198 GND 133 DDI0_TX3- 134 RSVD (N/C) 199 SPI_MOSI 200 SPI_CS0# 135 GND 136 GND 201 SPI_MISO 202 SPI_CS1# 137 DDI0_TX1+...
