EmETXe-i88U4
Form Factor
COM Express
Compact
®
Type 6 CPU Module
LAN
Intel
i210IT PCIe
®
Controller
♦ Technical Support
If you have any technical difficulties, please consult the user's manual first on our
website.
https://www.arbor-technology.com
Please do not hesitate to call or e-mail our customer service when you still can not
find out the answer.
https://www.arbor-technology.com
E-mail: info@arbor.com.tw
FCC Class B
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions : (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Copyright© 2018 All Rights Reserved.
COM Express
CPU
Intel
®
D1508D1527 Proceessor
I/O
USB 2.0/ USB 3.0/ SATA/
PCIe x1/ I2C/ DIO
Compact Type 6 CPU Module
®
Xeon D1539/
- 1 -
Quick Installation Guide
Memory
DDR4 ECC SO-DIMM
Sockets
4041880400100P
Version 1.0
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Arbor Technology EmETXe-i88U4
Summary of Contents for Arbor Technology EmETXe-i88U4
- Page 1 EmETXe-i88U4 COM Express Compact Type 6 CPU Module ® Quick Installation Guide Version 1.0 Form Factor Memory COM Express Compact Intel Xeon D1539/ DDR4 ECC SO-DIMM ® ® Type 6 CPU Module D1508D1527 Proceessor Sockets Intel i210IT PCIe USB 2.0/ USB 3.0/ SATA/ ®...
-
Page 2: Packing List
Module Type 2, 3, 4, 5 and 6 support two connectors with four rows of pins (440 pins) Connector placement and most mounting holes have transparency between Form Factors. The differences among the Module Type 6 and EmETXe-i88U4 are summarized in table below: Module Type... -
Page 3: Specifications
Specifications System ® Soldered onboard Intel Xeon D-1539 1.6GHz/D-1508 2.2GHz/D-1527 2.2GHzprocessor Memory 2 x DDR4 ECC SO-DIMM sockets BIOS AMI UEFI BIOS Watchdog Timer 1~255 levels reset USB 2.0 8 x USB 2.0 ports USB 3.0 4 x USB 3.0 ports Expansion Bus 1 x PCIex16 lane, 8 x PCIex1 lanes, I2C Interface Digital I/O... -
Page 4: Ordering Information
Ordering Information EmETXe-i88U4-D1539 Intel Xeon D1539 COM Express Compact Type 6 CPU module ® ® EmETXe-i88U4-D1508 Intel Xeon D1508 COM Express Compact Type 6 CPU module ® ® EmETXe-i88U4-D1527 Intel Xeon D1527 COM Express Compact Type 6 CPU module ®... -
Page 5: Board Dimensions
Board Dimensions - 5 -... -
Page 6: Connectors Quick Reference
Connectors Quick Reference Top Side Bottom Side - 6 -... - Page 7 COM Express AB Connector (bottom side) PCIE_RXN5 PCIE_TXN5 LAN_LED_LNK#_ACT LAN1_MDI3N DIO_6 LPC_FRAME# LAN1_MDI3P PCIE_RXP4 PCIE_TXP4 LPC_AD0 LAN_LED_100# PCIE_RXN4 PCIE_TXN4 LPC_AD1 LAN_LED_1000# LPC_AD2 LAN1_MDI2N PCIE_RXP3 PCIE_TXP3 LPC_AD3 LAN1_MDI2P PCIE_RXN3 PCIE_TXN3 +V3.3S LAN_LED_LNK# DIO_7 DIO_1 +V3.3S LAN1_MDI1N PCIE_RXP2 PCIE_TXP2 CLK_LPC_EXPRESS LAN1_MDI1P PCIE_RXN2 PCIE_TXN2 PCH_WAKE# CB_PWRBTN#...
- Page 8 COM Express CD Connector (bottom side) PE1_TX_DN_1 PE1_RX_DN_1 TYPE2# USB3_TXN1 USB3_RXN1 PE1_TX_DP_2 PE1_RX_DP_2 USB3_TXP1 USB3_RXP1 PE1_TX_DN_2 PE1_RX_DN_2 USB3_TXN2 USB3_RXN2 PE1_TX_DP_3 PE1_RX_DP_3 USB3_TXP2 USB3_RXP2 PE1_TX_DN_3 PE1_RX_DN_3 USB3_TXN5 USB3_RXN5 USB3_RXP5 PE1_RX_DP_4 USB3_TXP5 PE1_TX_DP_4 PE1_TX_DN_4 PE1_RX_DN_4 USB3_RXN6 USB3_TXN6 USB3_TXP6 USB3_RXP6 PE1_TX_DP_5 PE1_RX_DP_5 PE1_TX_DN_5 PE1_RX_DN_5 PE1_TX_DP_6 PE1_RX_DP_6...
