PIN
RS-232
Direction
1
NC
--
2
GND
--
Router Device
3
RXD
Router Device
4
TXD
5
GND
--
6
NC
--
PIN
RS-485
Direction
1
NC
--
2
GND
--
3
B
RS485_D-
4
A
RS485_D+
5
GND
--
6
NC
--
4. LED Indicators
Name
Color
Status
RUN
Green
On, fast blinking
(250 mSec blink time)
On, blinking
(500 mSec blink time)
Off
NET1
Green
On, solid
(Represents for
the Module1)
On, blinking
Off
Description
Router is powered on
(System is initializing)
Router starts operating
Router is powered off
Network is joined successfully by
using the Module1 card and worked
in an optimum one
Network is joined successfully but
worked in a lower-level than
standard
Network is not joined or joining
Name
Color
Status
NET2
Green
On, solid
(Represents for
the Module2)
On, blinking
Off
RSSI1
Green
On, solid
(Represents for
On, slow blinking
the signal value
of Module1)
(1 sec blink time)
On, fast blinking
Off
RSSI2
Green
On, solid
(Represents for
On, slow blinking
the signal value
of Module2)
On, fast blinking
Off
USR-SIM
Green
On, blinking
Off
USR-
Green
On, solid
OpenVPN
Off
USR-IPsec
Green
On, solid
Off
USR-WiFi
Green
On, solid
Off
WAN/ETH1/
Green
On, solid
ETH2/ETH3/
On, blinking
ETH4
Off
-3-
Description
Network is joined successfully by
using the Module2 card and worked
in an optimum one
Network is joined successfully but
worked in a lower-level than
standard
Network is not joined or joining
High signal strength (21-31) is
available
Medium signal strength (11-20) is
available
Low signal strength (1-10) is
available
No signal
High signal strength (21-31) is
available
Medium signal strength (11-20) is
available
Low signal strength (1-10) is
available
No signal
Backup card is being used
Main card is being used
OpenVPN connection is established
OpenVPN connection is not
established
IPsec connection is established
IPsec connection is not established
WiFi is enabled and working
properly
WiFi is disabled or not working
properly
Connection is established
Data is being transferred
Connection is not established
