REPLACEMENT OF PARTS (CONTINUED)
FAN & ATOM AIR VALVE (13)
Before assembling, check the air valve
is in fully open position by unscrewing
it counter-clockwise.
PISTON (15), O RING (16, 14 & 15C)
Unscrew the rear housing (19) at the back of the
gun body counter clockwise, pull out the needle
(18).
Use bent nose pliers "T" so to pull out the piston
which has a 12mm internal groove for this purpose.
Piston "P+W" and two valve "V" will pull out at
the same time. The ring "W" is located by pressing
it onto the piston body and can not be removed
from it.
The valve "V" can be removed easily from the
piston ring. We recommend to replace the full
piston at the same time (Item number SPA-60x-K).
DEVILBISS SPRAY GUN TECHNOLOGY—APPLICATION DETAILS
HVLP (BLUE)
Maintains Regulatory
Compliance
The DeVilbiss "Blue" Compact
gun allows you to maintain EPA
compliance
and
produce
superb finish.
Built to provide outstanding
coating atomization, the "Blue"
Compact can handle all types of
solvent
and
waterborne
materials.
High performance is coupled
with a gun body light in weight
and
designed
for
comfort to increase productivity.
SB-2-584-H (4/2016)
TRANS-TECH (GREEN)
Maximum Efficiency with
Environmental Responsibility
The DeVilbiss "Green" Compact
gun utilizes the very latest
a
advances in computational fluid
dynamics.
superior atomization with the
new
DeVilbiss
TECHNOLOGY.
Exceptionally efficient material
transfer for optimum coverage
and paint usage is achieved with
reduced
lowering your electrical needs
operator
and energy costs.
Exceed
requirements with the highest
atomization
accelerated application rate of up
to 600cc/min.
It's recommended to replace all the O-rings (14, 16
& 15c) in the gun body as soon you disassemble the
Piston from the gun.
Slightly lubricate the piston lip before fitting again
into the gun body. Use petroleum jelly to lubricate
the piston parts and o-rings.
