Typical System Layout - Rath VoIP Command Center Installation & Operation Manual

Typical System Layout

Base
Station
Distribution
Module
Power Supply
with UPS
120v Power Source
Two Wire Connection
Connection from
WAN Port on VoIP
Card to Network
Components
Ethernet from CPU
Card to Network
Components
Network Switch
Cat 5E or Cat 6E cabling
Note: Local and/or state
codes may have additional
cabling requirements. Please
check with your local AHJ.
Components
Network
Router
Rath IP Phone
HELP PHONE
SOLID LIGHT: CALLING
BLINKING LIGHT: RECEIVED
HELP PHONE
SOLID LIGHT: CALLING
BLINKING LIGHT: RECEIVED
HELP PHONE
SOLID LIGHT: CALLING
BLINKING LIGHT: RECEIVED
HELP PHONE
SOLID LIGHT: CALLING
BLINKING LIGHT: RECEIVED
Maximum wire run
between connected
devices is 300'
Page 4
