Summary of Contents for Rath 2500 SPRVSR Series
- Page 1 Installation & Operations Manual Supervisor Board 2500-__SPRVSR RP8500SPRVSR N56W24720 N. Corporate Circle Sussex, WI 53089 Ver. 8 Made in the USA 800-451-1460 www.rathcommunications.com 07/20 3 Year Warranty...
-
Page 2: Table Of Contents
Thank you for purchasing a RATH® Supervisor Board. We are the largest Emergency Communication Manufacturer in North America and have been in business for over 35 years. We take great pride in our products, service, and support. Our Emergency Products are of the highest quality. -
Page 3: Items Needed
Items Needed Included: Not Included: • 2500-__ SPRVSR Supervisor Board(s) • 110 style punch tool • 4 pair RJ11 pigtail cables (quantity based on • Distribution Module (sold separately with Command Center model number) Base Station) • 12vdc power transformer •... - Page 4 Card 1 Example: 2004 PHONE 4 2002 PHONE 2 2001 PHONE 1 To punch down 19 2003 or 20 on Supervisor PHONE 3 Board (if using) TELCO LINE 2 Note: Do not use TELCO LINE 1 the green and brown pairs •...
- Page 5 For 92 zone systems, five Supervisor Boards are included. Wire as shown below: Supervisor Board 2 Supervisor Board 1 Supervisor Board 5 Supervisor Board 4 Supervisor Board 3 2500-___SPRVSR 2500-___SPRVSR 2500-___SPRVSR 2500-___SPRVSR 2500-___SPRVSR POWER IN POWER IN POWER IN POWER IN POWER IN Flex Ports Can RETURN...
- Page 6 • Each additional card is used for connecting phones: • Port 1: (S01-S04) connection for up to 4 Emergency Phones • Port 2: (S05-S08) connection for up to 4 Emergency Phones • Port 3: (S09-S12) connection for up to 4 Emergency Phones •...
-
Page 7: Connecting The Power Supply
Wiring Call Boxes to Supervisor Board 1. Using the provided RJ11 pigtail cables, plug the RJ11 end of the cable into the RJ11 jack on the front of the Supervisor Board. The wire color on the jack should match what is punched down on the back. 2. -
Page 8: Setting Switches
Setting Switches The factory default setting for the switches is in the DISABLE position. Set the switches on all the monitored ports to the ENABLE position. Any port that has equipment connected to it should be monitored. Setting Check Interval 1. -
Page 9: Testing
22/24ga Single Pair 2400 Series Call Box Twisted, Shielded 2400 Series Wire Recommended Call Box 2400 Series Call Box 22/24ga Single Pair Communication Failure RATH® Supervisor Relay Output Fire Addressable Fire Control Power Failure Outside Provided Alarm Relay Output Panel Phone Line by RATH®...
