- Page 1 Installation & Operations Manual ARE YOU TRAPPED? SmartView Visual Communication System N56W24720 N. Corporate Circle Sussex, WI 53089 RP850001SV Ver. 12 YEAR 800-451-1460 www.rathmicrotech.com 8/22 WARRANTY...
-
Page 2: Table Of Contents
Thank you for purchasing the SmartView Visual Communication System. We are the largest Emergency Communication Manufacturer in North America and have been in business for over 35 years. We take great pride in our products, service, and support. Our Emergency Products are of the highest quality. -
Page 3: Pre-Installation Requirements
1. Internet Connection: • Routed internet connection using DHCP (Network must use private IP address ranges 10.X.X.X or 192.X.X.X or 172.X.X.X) • Cellular modem with data (available from RATH ® 2. Laptop with a network connection for testing 3. Power Option: 2100-SVE Ethernet Extenders 4. -
Page 4: Operations And Testing
• In some cases, a firewall will block the SmartView device. An exception may need to be made for the device in firewall settings. Contact RATH ® the MAC address of your device if necessary. -
Page 5: Controller Layout
Controller Layout Installation & Wiring Diagrams Wiring with Ethernet Extenders (2100-SVE) (Must be Supplied by RATH ® Notes: Machine Room • 2-wire from main Extender to remote Extender Machine Room Outbound • Ethernet Patch Cable from communication source to main... - Page 6 Wiring Example (Preferred Option for Standard Travel Cable): • Extender Power: Supplies 1A to the SmartView Controller • Extender Wiring: • Extends up to 1,640 feet over single pair of wiring between Extenders (requires single pair, 18-24ga, shielded or unshielded) RJ45 Adapters Included •...
- Page 7 Appendix A SmartView Controller Specifications: • Power Requirements: 12v or 24v via Extender • Curent Draw: 12v Active = 1A 12v Idle = 0.5A 24v Active = 0.5A 24v Idle = 0.25A • Operating Temperature: 32°F to 158°F (0°C to 70°C) •...
- Page 8 Appendix B Example ID Table: SmartView ID Location/Description 10020 Elevator 1 10021 Elevator 2 ID Table: SmartView ID Location/Description Page 8...
