CRD4610-1
CrystalClear™ AC '97 Motherboard Reference Design
CRD4610-1 Revised: Thursday, June 19, 1997
48 2 R31,R34
49 2 R42,R41
50 2 S1,S2
51 1 U1
52 1 U2
53 1 U3
54 1 U4
55 2 U5,U6
56 1 U10
57 1 U9
58 1 Y1
DO NOT POPULATE
2 R25, R28
1 J3
DS241RD1C1
20K PHILIPS
1 MEG PHILIPS
EVQ-PHP03T
CS4297-KQ CRYSTAL
CS4610-CM CRYSTAL
X24C04 ATMEL
TDA1308 PHILIPS
MC33078D MOTO
LT1117CST-3.3 LINEAR
TECHNOLO
GY
MC78M05CDT MOTOROLA MC78M05CDT
24.576 MHz EPSON
0 PHILIPS
4X1HDR SAMTEC
CIRRUS LOGIC ADVANCED PRODUCT DATABOOK
9C06031A2002J RES,20K,SO,0603,5%,1/10W,METAL
FILM
9C06031A1004J RES,1M,SO,0603,5%,1/16W,METAL
FILM
EVQ-PHP03T PUSH BUTTON SWITCH
CS4297-KQ_0 AC '97 Serial CODEC w/ 3D
CS4610-CM PCI AUDIO ACCELERATOR
AT24C04N-10SC IC,24C04,512X8BIT,SO,SOIC8,EEPR
OM
TDA1308S8 IC,1308,SO,SOIC8,LOW NOISE
HEADPHONE AMP
MC33078D IC,33078,SO,SOIC8,DUAL OP AMP
LT1117CST-3.3 3.3V REGULATOR, SOT_223, 0.2%,
800mA
+5V REGULATOR, DPAK, 2%,
500MA
CA-301_24.576M- CRYSTAL, 24.576MHz, CA-301, Fund
C Mode Par Res
9C06032A0R00J RES,0,SO,0603,5%,1/10,METAL
FILM
TSW-104-07-T-S HDR,4X1,0.025"PIN,0.1"CTR
