Cirrus Logic CRD4610-1 Reference Design page 16

ALT_LINE_OUTR
ALT_LINE_OUTL
VREF
16
CrystalClear™ AC '97 Motherboard Reference Design
2
3
C59
RP6
1 4 1
2 3 2
RP7
27k
C62
6
5
+5VA
Place close as possible to U4
C58
0.1uF
Y5V
AGND
Figure 13. Headphone Amplifier
CIRRUS LOGIC ADVANCED PRODUCT DATABOOK
+5VA
U4A
TDA1308
8
-
1
+
4
AGND
22pF
+
220uF
NPO
C60
ELEC
4
3
39k
+
220uF
C61
ELEC
22pF
NPO
+5VA
8
U4B
-
7
+
TDA1308
4
AGND
CRD4610-1
R8 10
HP_OUT_R
1/4 WATT
R9 10
HP_OUT_L
1/4 WATT
4 3
RP8
47K
1 2
AGND
DS241RD1C1
