1500 Series
Electric Strike
Installation & Operating Instructions
Product Components
A
1500 Series
or 1600 Series
®
B
Trim Enhancer & Screws
C
5/64" Hex Wrench
D
#6-32 x 3/16" Phillips Head Screws to Mount Trim Enhancer
E
12 & 24 Volt Plug In Connectors
Electrical Specifications
Electrical Ratings
for Solenoid
Continuous Duty
Voltage
12 VDC
Resistance in Ohms
50
Amps
.24
Solenoids are rated at +/– 10% indicated value.
* 10% max duty cycle (2 min. max on time)
For inductive kickback protection, consider using with the HES 2005M3
SMART Pac® III or 2001M Plug-in Bridge Rectifier with built-in MOV.
Minimum Wire Guage Requirements
Voltage
200 feet or less
200–300 feet
300–400 feet
The above table applies to Models 1500, 1500E, 1600, and 1600E.
Lengths based on round trip.
1500 | 1600 Series UL1034 Rating
Static Strength
Dynamic Impact
Endurance
UL294 Performance Levels*
Destructive Attack
Line Security
Endurance
Standby Power
* Monitor options were not evaluated by UL294/UL1034/ULC60839-11-1
| 1600 Series
®
Electric Strike Body
®
Intermittent Duty*
24 VDC
12–16 VAC
24 VAC
200
50
200
.12
.24–.32
.12
12 VDC
24 VDC
18 guage
20 guage
16 guage
18 guage
14 guage
16 guage
1,500 lbs
70 ft–lbs
250,000 cycles
Level I (No attack test)
Level I (No line security)
Level IV (100,000 cycles)
Level I (No secondary power source)
®
A
B
D
Faceplate Options
Description
Cylindrical locksets with up to 3/4" throw
For Use With
and all locksets with center-lined bolts.
1J
Compatible With All brands of cylindrical latchbolts.
For Use With
Mortise locksets with up to 3/4" throw latchbolt.
1K
Compatible With Baldwin, Marks and PDQ.
For Use With
Mortise locksets with up to 3/4" throw latchbolt.
Accurate, Arrow, Best, Corbin Russin, Falcon,
1KM
Compatible With
Sargent (7800, 8200, 9200), ASSA ABLOY
ACCENTRA
For Use With
Mortise locksets with up to 3/4" throw latchbolt.
Dorma (9500), Jackson, Sargent (7700,
1KD
Compatible With
8100), Schlage, ASSA ABLOY ACCENTRA
8700 (formerly Yale Commercial).
Mortise locksets with deadbolt for
For Use With
night latch function only.
1N
Compatible With Accurate, Baldwin, Marks, Omnia, PDQ, Schlage.
Mortise locksets with deadbolt for
For Use With
night latch function only.
Accurate, Arrow, Baldwin, Corbin Russwin,
1NM
Falcon (45H, 47H, 34H, 37H), Marks, PDQ,
Compatible With
Sargent (7800, 8200, 9200), ASSA ABLOY
ACCENTRA
Mortise locksets with deadbolt for
For Use With
night latch function only.
1ND
Sargent (7700, 8100), Schlage, ASSA ABLOY
Compatible With
ACCENTRA
Mortise locksets with a normally extended
For Use With
1" deadbolt and center-lined deadlatch.
1NTD
Accurate, Arrow, Baldwin, Marks,
Compatible With
Omnia, PDQ, Schlage.
C
E
8800 (formerly Yale Commercial).
8800 (formerly Yale Commercial).
8700 (formerly Yale Commercial).
1
