7000 Series
Electric Strike
Installation Instructions
Product Components
A
7000 Series Electric Strike Body
B
12-Volt and 24-Volt Plug In Connectors
C
Pigtail Connectors
Specifications
Electrical Ratings
for Solenoid
Continuous Duty
Voltage
12 VDC
Resistance in Ohms
50
Amps
.24
Solenoids are rated at +/– 10% indicated value.
* 10% max duty cycle (2 min. max on time)
For inductive kickback protection, consider using with the HES 2005M3
SMART Pac
III or 2001M Plug-in Bridge Rectifier with built-in MOV.
®
Minimum Wire Guage Requirements
Voltage
200 feet or less
200–300 feet
300–400 feet
Lengths based on round trip.
7000 Series Rating: For Indoor Use Only
Model
Static Strength
Dynamic Impact
Endurance
500,000 cycles
UL294 Performance Levels*
Destructive Attack
Line Security
Endurance
Standby Power
* Monitor options were not evaluated by UL294/UL1034/ULC60839-11-1
Intermittent Duty*
24 VDC
12–16 VAC
24 VAC
200
50
.12
.24–.32
12 VDC
24 VDC
18 guage
20 guage
16 guage
18 guage
14 guage
16 guage
791 / 792
783S / 786S / 789S
1,500 lbs
1,000 lbs
70 ft–lbs
50 ft–lbs
500,000 cycles
Level I (No attack test)
Level I (No line security)
Level IV (100,000 cycles)
Level I (No secondary power source)
200
.12
A
B
or
C
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the h.e.s. 7000 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Assa Abloy h.e.s. 7000 Series

  • Page 1 7000 Series Electric Strike Installation Instructions Product Components 7000 Series Electric Strike Body 12-Volt and 24-Volt Plug In Connectors Pigtail Connectors Specifications Electrical Ratings for Solenoid Continuous Duty Intermittent Duty* Voltage 12 VDC 24 VDC 12–16 VAC 24 VAC Resistance in Ohms Amps .24–.32 Solenoids are rated at +/–...
  • Page 2 Installation WARNING: Before connecting any device at the installation site, verify input voltage using a multimeter. Many power supplies and low voltage transformers operate at higher levels than listed. Any input voltage exceeding 10% of the solenoid rating may cause severe damage to the unit. Installation wiring for the product and wiring methods shall be in accordance with the National Electrical Code, ANSI/NFPA 70.
  • Page 3 Installation (continued) Adjusting the Horizontal Diagram 3: Diagram 3a: Loosen Screws Shift Positioning For 791 and 792 Options LOOSEN the screws, but DO NOT REMOVE as shown in Diagram 3. SHIFT the electric strike to the proper horizontal position and TIGHTEN the screws as shown in Diagram 3a.
  • Page 4 Printed in the U.S.A. Patent pending and/or patent www.assaabloydss.com/patents techsupport.hes@assaabloy.com Copyright © 2024, Hanchett Entry Systems, Inc., an ASSA ABLOY Group company. hesinnovations.com | 800 626 7590 All rights reserved. Reproduction in whole or in part without the express written...
