Chapter 6: Board Test System
Using the Board Test System

The SSRAM Tab

The SSRAM tab allows you to read and write SRAM and flash memory on your
board.
Figure 6–4. The SSRAM Tab
The following sections describe the controls on the SSRAM tab.

Read

The Read control reads the SRAM on your board. To see the SRAM contents, type a
starting address in the text box and click Read. Values starting at the specified address
appear in the table.

Write

The Write control writes the SRAM on your board. To update the SRAM contents,
change values in the table and click Write. The application writes the new values to
SRAM and then reads the values back to guarantee that the graphical display
accurately reflects the memory contents.
October 2012 Altera Corporation
Figure 6–4 shows the SSRAM tab.
