Typical Applications; Operating Conditions; What's In The Box - OnRobot VG10 User Manual

Typical applications

•
Pick and place
•
Palletizing
•
Machine tending
•
Material handling

Operating conditions

Power supply
Current consumption
Operating temperature
Relative humidity (non-condensing)
Calculated MTBF (operating life)

What's in the box?

Everything you need to get started with the VG10 is included:
•
1 x VG10 Industrial Robot Vacuum Gripper
•
1 x Easy Tool Changer
•
1 x 200 mm M8 tool cable
•
16 x Fittings for vacuum cups (pre-mounted)
•
16 x 30 mm vacuum cups (pre-mounted)
•
4 x 40 mm vacuum cups
•
4 x 15 mm vacuum cups
•
16 x Blind screws
•
4 x Torx T30 M6 bolts
•
1 x pin (rotation lock)
•
Torx 30 key
•
3 mm Allen hex key
•
User manual
•
USB stick
URCaps (PolyScope >= 3.3 support)
-
User manual
-
Minimum Typical
20.4 24
50 600
0 -
32 -
0 -
30000 -
Maximum Unit
28.8 Volts
1500 mA
50 °C
122 °F
95 %
- hours
