1. Connecting the Moni-
tor to a Computer
Establishing a one-to-one connection from the
monitor to a computer. Using a LAN cable (Cat-
egory 5, cross-over type) you can configure
the monitor via the computer.
1
Disconnect the computer's LAN
cable from the existing network.
2
Connect a LAN cable (a UTP
cable, Category 5, cross-over
type) to the monitor's LAN ter-
minal and connect the other end
of the cable to the computer's
LAN terminal.
3
Plug the power cord into the AC
socket of the monitor.
4
Turn on the computer.
Info
Confirm that the LINK LED on the rear of the
monitor illuminates. If the LINK LED does not
illuminate, check the following :
• The LAN cable is properly connected.
• The power switches of both the monitor and
the computer are on.
This completes the connection. Now proceed to "2. Setting an IP Address for the
Computer".
Setting up the Monitor Network Environment
A LAN cable being
connected to the network
LAN cable
(cross-over type, commercially available)
ON
