Sharp TL-M5200 Setup Manual page 37

4
Turn on all of the monitors.
5
Access the monitor 1 from the com-
puter via Internet Explorer.
(See "Controlling the Monitor Using Internet
Explorer (Version 5.0 or later)" on page
the details.)
6
Click "Master & Slave" on the menu.
7
Select "Master" on "Master & Slave
Setting".
• "Slave Address" display will appear.
8
Make the IP address for each moni-
tor as shown below.
• Slave 1 : 192.168.150.4
• Slave 2 : 192.168.150.5
• Slave 3 : 192.168.150.6
9
Click the "Apply" button.
10
Access the monitor 2 from the com-
puter via Internet Explorer.
(See "Controlling the Monitor Using Internet
Explorer (Version 5.0 or later)" on page
the details.)
11
Click "Master & Slave" on the menu.
12
Select "Slave" on "Mater & Slave
Setting".
16 for
16 for
Multi Screen Projection
-37
