Setting up the Multi Screen Projection Controlling
When you want to control the monitors collectively for the multi screen projection, connect LAN cables to
the LAN terminals and set both "TCP/IP" and "Master & Slave".
Following is an example of how to use 4 monitors in a daisy chain connection.
LAN terminal
LAN terminal
LAN terminal
LAN terminal
LAN cable (straight-through type)
Multi Screen Projection
Computer
LAN cable
Hub
-35
