Sharp TL-M5200 Setup Manual page 38

Multi Screen Projection
13
Repeat the same procedure from
the step 10 to 12 for the monitor 3
and 4.
14
Select inputs as specified in the
table on the right.
(See page 36 on the monitor operation
manual.)
Note
• Set input terminals you will use to "ON". Set
input terminals you will not use to "OFF".
15
Turn off all of the monitors.
16
Make connections following the
diagram shown on page 35.
17
Turn on the monitors first, then turn
on the computers and the video
equipment.
Note
• Image quality may deteriorate when picture sig-
nals are input through multiple monitors with an
RGB cable in a daisy chain connection.
Info
• To set up the multi screen projection, assign a monitor as the master and the other monitor as the slave
and connect the monitors with commercially available LAN cables (UTP cable, Category 5, cross-over
type). In this way, you can control the both monitors with one remote control.
• The buttons below can control both the master and the slave at one time.
• ON button
• STANDBY button
• DIRECT INPUT buttons
(COMPUTER1, COMPUTER2, DVI, • FREEZE button
HDMI, S-VIDEO, VIDEO)
• AV MUTE button
• VOLUME buttons
• In normal operation, the monitor set as the slave cannot be controlled by the remote control.
• Even while the monitor is set as the slave, the buttons on the monitor can be used.
-38
COMPUTER 1
COMPUTER 2
DVI
HDMI
VIDEO
S-VIDEO
• AUTO SYNC button
• RESIZE button
• AV MODE button
• P&P button
• SELECT button
Monitor 1 Monitor 2-4
Master
Set Inputs Set Inputs
COMPUTER 1
ON
COMPUTER 2
ON
DVI
OFF
HDMI
OFF
VIDEO
OFF
S-VIDEO
ON
Slave
ON
OFF
OFF
OFF
OFF
ON
