Installation and Wiring

■Installation

Connect valve manifold to the SI unit.
•Dimensions for installation
n
L 1
L1
L2
n
L 9
L1 232.7
L2 192
The above table shows dimensions as an example for the SY5000 series valve manifold.
Connectable valve manifolds are the same as for EX250 series SI unit.
Refer to the EX250 series valve manifold section in the valve catalogue for valve manifold dimensions.
2 3 4
120.7 136.7 152.7
80 96 112
10 11 12
248.7 264.7 280.7
208 224 240
-10-
n: number of valve stations
5 6 7
168.7 184.7 200.7
128 144 160
13 14 15
296.7 312.7 328.7
256 272 288
8
216.7
176
16
344.7
304
(mm)
No.EX※※-OMP0005-E
