Mounting Information

Model Number Size
2975-9405 4-Unit
2975-9406 6-Unit
IMPORTANT: Distance between close coupled dual cabinets
must be no less than 3 inches (76 mm) and no
more than 24 inches (610 mm)

General Operating Specifications

Input Power Requirements
Mains Input, 230 VAC base models
Mains Input with 230 VAC expansion power supply
Mains Input, 4100-0263, 100 W Amplifier
Environmental
Ambient Temperature Range
Relative Humidity Range
Solar Radiation
Simplex, the Simplex logo, MAPNET, and TrueAlarm are either trademarks or registered trademarks of Simplex Time Recorder Co. in
the U.S. and/or other countries.
Height Cabinet Width
36 1/4" (921 mm)
52 1/8" (1324 mm)
All specifications and other information shown were current as of printing and are subject to change without notice.
Cabinet Depth
25 3/4 6 3/4"
(654 mm) (171 mm)
2 1/4"
(57 mm)
(76 mm)
Installation Detail Side View
1 A maximum
2 A maximum
2 A maximum per amplifier
23°F to 113°F (-5° C to 45° C)
5% to 95%, condensation or ice formation is permissible
on the outside of the unit
2
700 W/cm
visit us on the world wide web at www.simplexnet.com
Door Width
26 3/8"
(670 mm)
7 3/4"
(197 mm)
See chart
3"
3 3/4"
(95 mm)
195 to 253 VAC,
50/60 Hz
S4100-0025 (EN54) 5/99
