Master Controller Module
The 4100/4120-7014 Master Controller Board provides
system control, synchronization, and supervision of all
modules, continuously scanning each module for status
changes. Features include:
• Operator's Panel with LCD and operator keys
• General Fault Output
• General Alarm Output, form "C" contact output
• RS-232 Dual Port Communications Module,
one port is dedicated to control the user interface
panel, one port is unassigned (can be connected to
remote LCD Annunciator 4604-9202UK)
• Battery Charger for up to 110 Ah Batteries
– Batteries up to 42 Ah may be mounted in the bottom
of the control cabinet
– Batteries larger than 42 Ah mount external to main
control cabinet
• Intelligent Power Supply:
– Two isolated outputs of 4 Amps each at 28.5 VDC
when mains powered (24 VDC nominal during
battery operation)
– Tap "B" provides 4 A for general purpose sounder
circuits and control power
– Tap "A" provides 2 A (typical) for sounder circuits
controlling "clean" loads with controlled inrush
current and proper transient suppression (actual
available power depends on total system power
requirements)
Optional Modules Description
• Conventional Zone Circuits:
– Eight circuit zone modules provide system expansion
as Class B operation
– Capable of supporting two-wire Simplex smoke
detectors and electronic heat detectors plus normally
open contact devices (manual stations, mechanical
heat detectors, etc.)
• Sounder and Speaker Circuits:
– Two, four, or six circuit modules provide Class B
system expansion
– Circuit ratings: 2 A @ 24 VDC; 50 W @ 25 VRMS
(for speaker circuits), or for up to 6 telephones
– Supervised for opens, grounds, and wire-to-wire
shorts
– Dual and Triple channel modules have integral
switching relays for selecting the proper audio
channel output
– Outputs can be programmed for temporal code or
march time code
• RS-232 Dual Port Communication Module:
– Up to four additional RS-232 modules total
– Each port can be vectored by event category
Simplex Time Recorder Co.
• Auxiliary Control Relays:
– Built-in fuse protection per contact
– Feedback tracks on/off status of remote devices
– 4100-3001, four CPU controlled relays, DPDT
contacts rated for 2 A @ 24 VDC
– 4100-3002, four CPU controlled relays, DPDT
contacts rated 10 A @ 24 VDC
– 4100-3003, eight CPU controlled relays, SPDT
contacts rated 3 A @ 24 VDC
• LED Annunciation:
– Optional interface modules are available for remote
and/or local control panel annunciation. The LEDs
are programmable for slow rate, fast rate pulse, or
steady illumination.
• 64/64 LED/Switch Controller:
– Interfaces up to 64 LEDs and 64 switches to the
master controller via serial communications
– Continuously monitors switches for changes in status
– Supervises and controls LEDs
– Supervises LED/switch module placement
• 24 Point I/O Graphic Interface:
– Each of the 24 points can be individually configured
as either a switch input or a lamp driver output
– 150 mA lamp driver output (+24 VDC common)
– Outputs can be steady, slow pulse, or fast pulse
– Switch inputs can monitor two position or three
position switches
– Lamp test input
• LED/Switch Modules:
– Modules contain socketed LEDs to allow
interchanging with different color LEDs to indicate
function
– Switch modules can be used to perform manual
control such as for HVAC, pressurization fans,
damper control, speaker circuits, etc.
• MAPNET II
®
, TrueAlarm
Module:
– Connections for up to 120 MAPNET II addressable
devices or TrueAlarm analog sensors per module
– MAPNET II Line Isolator Modules are available for
protecting Class A addressable circuit loops from
short circuits
• Remote Unit Interface (RUI) Modules:
– Provides a supervised serial communication channel
for control and monitoring of remotely located mimic
panels, MINIPLEX transponders, and I/O panels
3
®
