- Page 1 ACCENT 800 FLAME EFFECT SPACE HEATER INSTALLATION & OPERATING MANUAL The Real Flame Accent 800 space heater is suitable to be installed into a frame out installation. Designed to operate on Natural gas and ULPG gas. Approval no.GMK 10528 VERSION 3...
- Page 2 Date Of Purchase / settlement of property if new home _________________ Model / Serial Number_______________________ This warranty does not cover the cost of claiming under the warranty or transporting the Real Flame Gas Burner to and from the supplier. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage.
- Page 3 WARNING The Accent 800 space heater has a primary safety glass fitted in front of the glass door. This safety glass is fitted to this appliance to reduce the risk of injury from burns and at no time should this glass be permanently removed.
-
Page 4: Table Of Contents
Installation Instructions Setup with external wall mounted fan terminal..........9 Setup with rooftop termination..............14 Timber Frame Installation ..................18 Media Installation....................19 Commissioning Procedure..................23 Operation - User Instructions................24 Troubleshooting ....................29 Remote Control.....................30 Wiring Diagram .....................31 Conversion Details....................32 Parts List.......................33 Real Flame Contact Information ................36... -
Page 5: Data Plate
(Affixed to the base of the unit for reference to gas pressure & consumption) DATA PLATE MODEL ACCENT 800 INJECTOR SIZE N.G.C. (Mj/hr) GAS TYPE Natural Gas 1 X 2.50mm 0.40kPa High / 0.47kPa Low 26.5 High/19 Low ULPG 1 X 1.38mm 2.60kPa High / 1.60kPa Low... -
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS LOC TION Select a location where the fire can be supervised during operation. An electrical isolation switch must be fitted at the appliance or on an adjacent wall to allow for emergency shutdown and maintenance. Installation must meet Australian gas codes AS/NZS 5601. INST LL TION CLE R NCES –... -
Page 7: Flue Termination
(continued) INSTALLATION INSTRUCTIONS FLUE TERMIN TION LOC TION • Flue terminations shall not be recessed in walls or sidings. • EXTREMELY IMPORT NT: In heavy snow areas take extra care to prevent blocking flue termination with snow removal equipment. • Flue gases exiting flue terminals are very hot and must not be restricted to assure fireplace combustion is not affected. - Page 8 ACCENT 800 FLUE TERMINATION (COWLS)
- Page 9 (continued) INSTALLATION INSTRUCTIONS SETUP WITH EXTERN L W LL MOUNTED F N TERMIN L Wall mounted fan terminal 1/ Wall mounted fan module – terminal must be installed with clearances as specified by AS/NZS 5601.1 Clause 6.9.3 2/ Run exhaust flue and air intake flue as required –...
- Page 10 (continued) INSTALLATION INSTRUCTIONS Recommended Silicon – Non-acetic, neutral cure 150degc or higher temperature rated. Bostik RTV 926 or similar. Apply an 8mm thick silicon bead fully around heater connection approx. 10mm from the top. Apply an 8mm thick silicon bead fully around the lower fan connection spigot approx. 10mm from the end.
- Page 11 (continued) INSTALLATION INSTRUCTIONS Remove cover from fan terminal Cut flue exhaust tube (hot tube) to length (Approximately flush with wall exit). Wall termination will sit against wall. Pull flue tube through approx 100mm further (will be pushed back once terminal fitted). Cut Air intake flue 40mm longer.
- Page 12 (continued) INSTALLATION INSTRUCTIONS Ensure ends are burr free and round, test fit flue will slide over connection. Apply an 8mm thick silicon bead fully around flue connection plate spigot approx. 10mm from the top. Apply an 8mm silicon bead fully around the inside of the flue end (heater connection end) Slide flue onto connection spigot fully.
- Page 13 (continued) INSTALLATION INSTRUCTIONS Fit front cover...
-
Page 14: Timber Frame Installation
TIMBER FRAME INSTALLATION 2 x 84mm OD FLUES TRIM Plaster to run beyond stud and behind trim Frameout Dimensions (in mm) 1500 * Indication only. Can be smaller or larger. -
Page 15: Media Installation
MEDIA INSTALLATION Media must be setup as per instructions • The media is designed and shaped to correctly locate and remain in the correct position. • DO not add extra media, or combine media types. • Only the approved supplied media is to be used. •... - Page 16 (continued) MEDIA INSTALLATION Insert log 3 Insert log 4 Insert log 5...
- Page 17 (continued) MEDIA INSTALLATION Insert log 6 Insert log 7...
- Page 18 (continued) MEDIA INSTALLATION Insert log 8 Finished assembly...
-
Page 19: Commissioning Procedure
COMMISSIONING PROCEDURE Once the fire is installed. • Install media. • Connect to gas and power. • Fit firebox door. • Check for gas leaks. • Connect powerflue module loom to fan control unit. • Carry out the lighting procedure. •... -
Page 20: Operation - User Instructions
In the event of abnormal operation please contact your licensed gas installer, gas service personnel or Real Flame Pty Ltd. Abnormal operation may consist of the following, noisy fan, excessive or small flame, unusual flame appearance or colour, excessive sooting or other. - Page 21 (continued) OPERATION – USER INSTRUCTIONS • TTENTION: TURN OFF THE MAIN GAS SUPPLY OF THE APPLIANCE DURING INSTALLATION OR MAINTENANCE OF THE RECEIVER DEVICE. • TURN OFF MAIN GAS SUPPLY TO THE APPLIANCE PRIOR TO REMOVING OR REINSERTING THE BATTERIES. •...
- Page 22 (continued) OPERATION – USER INSTRUCTIONS Turn off the appliance With the system ON, press the ON/OFF key on the transmitter. The transmitter LCD display will only show the room temperature. At the same time the receiver will turn off the appliance. A single “beep” from the receiver confirms reception of the command.
- Page 23 (continued) OPERATION – USER INSTRUCTIONS Smart thermostat (Transmitter Operation) The smart thermostat function adjusts the flame height in accordance with the difference between the set point temperature and the actual room temperatures. As the room temperature gets closer to the set point the smart function will modulate the flame down. To activate this function, press the thermostat key until the word “SMART”...
- Page 24 (continued) OPERATION – USER INSTRUCTIONS Key Lock This function will lock the keys to avoid unsupervised operation. To activate this function press the Mode and Up keys at the same time. To de-activate this function, press the Mode and Up keys at the same time.
-
Page 25: Troubleshooting
If new appliance - run for several hours, open all operating room ventilation and allow paint to cure. • Turn off appliance and the have door seal inspected by service personnel or Real Flame agent. Room air fan is noisy Faulty or dirty fan •... -
Page 26: Remote Control
Remote – no faults codes available. If your fireplace still does not operate correctly consult your dealer, installer or gas service technician. All service and repairs should be performed by an authorised agency All spare parts are available from Real Flame Pty Ltd. -
Page 27: Wiring Diagram
WIRING DIAGRAM... -
Page 28: Conversion Details
CONVERSION DETAILS Natural gas / ULPG. Electrical tray must be slid forward to reprogram a remote control. Valve, pilot injector and main burner injector must be changed to suit gas type. Turn the remote to off mode Turn mains power to heater on. Press the red button on the receiver once –... -
Page 29: Parts List
PARTS LIST Valve SIT Pilot assembly Injector Burner Remote control Sit Ignition pack / gas control... - Page 32 GLEN DIMPLEX AUSTRALIA PTY LTD ABN 69 118 275 460 Head Office/Factory/Showroom 1340 Ferntree Gully Rd. Scoresby Vic 3179 Ph: (03) 8706 2000 Fax: (03) 8706 2001 E-mail: info@realflame.com.au Richmond - VIC Showroom 300 Swan St. Richmond Vic 3121 Ph: (03) 9428 4443 Fax: (03) 9428 4445 Dandenong - VIC Showroom 3/328 South Gippsland Highway, Dandenong South Vic 3164...
