- Page 1 EG-SR-7100A User’s Manual (Version 4.1) ©2005 WIZnet Co., Inc. All Rights Reserved. ☞ For more information, visit our website at http://www.wiznet.co.kr...
- Page 2 WIZnet’s Online Technical Support If you have something to ask about WIZnet Products, Write down your question on Q&A Board in WIZnet website (www.wiznet.co.kr). WIZnet Engineer will give an answer as soon as possible. EG-SR-7100A User’s Manual (Ver. 4.0)
- Page 3 COPYRIGHT NOTICE Copyright 2005 WIZnet, Inc. All Rights Reserved. Technical Support: support@wiznet.co.kr Sales & Distribution: sales@wiznet.co.kr General Information: info@wiznet.co.kr For more information, visit our website at http://www.wiznet.co.kr EG-SR-7100A User’s Manual (Ver. 4.0)
-
Page 4: Table Of Contents
3.1. Using Configuration Tool Program ..............12 3.2. Using serial upload .................... 14 4. Serial Configuration ....................15 5. Pin Assignment and Dimension................17 6. Demonstration and Test .................... 19 7. Reference Schematic ....................23 EG-SR-7100A User’s Manual (Ver. 4.0) - Page 5 .......... 22 ECEIVED ATA BY ETWORK ERMINAL ROGRAM Tables 1.1 EG-SR-7100A M ABLE ODULE PECIFICATION ................2 1.2 S ABLE ERIAL ESCRIPTION .......................3 5.1 EG-SR-7100A M ABLE ODULE UNCTIONS ................17 5.2 EG-SR-7100A D ABLE IMENSION ....................18 EG-SR-7100A User’s Manual (Ver. 4.0)
-
Page 6: Introduction
1. Introduction EG-SR-7100A is a gateway module that converts RS-232 protocol into TCP/IP protocol. It enables remote gauging, managing and control of a device through the network based on Ethernet and TCP/IP by connecting to the existing equipment with RS-232 serial interface. -
Page 7: Eg-Sr-7100A Test Board
Connector type 2x12 2mm Pin header array Size 50mm x 30mm x 8.85mm Table 1.1 EG-SR-7100A Module Specification 1.2.2. EG-SR-7100A Test board Fig 1.1 EG-SR-7100A Test Board For normal operation, the position of the mode switch should be upper ☞... -
Page 8: Serial Interface
1.2.2.1. Serial Interface Fig 1.2 Serial Pin Assignment of EG-SR-7100A Test Board Pin Number Signal Description Not Connected Receive Data Transmit Data Data Terminal Ready Ground Data Set Ready Request To Send Clear To Send Not Connected Table 1.2 Serial Pin Description... -
Page 9: Led
1.2.2.2. Power LED: displays power status of EG-SR-7100A ① Link LED: indicates network link is established ② 10 LED: indicates network speed is 10M bps ③ 100 LED: indicates network speed is 100M bps ④ Collision LED: indicates a packet transmitted from the Ethernet controller to ⑤... -
Page 10: Getting Started
2.1. Hardware Installation Procedure Follow these steps to prepare the module and evaluation board for testing. STEP1: Plug the EG-SR-7100A module into the sockets on the test board. Be careful of connecting the JP1 on the module to the correct JP1 on ☞... -
Page 11: Configuration Tool Features
2.2. Configuration Tool Features Fig 2.1 Configuration Tool Initialization Window (Network Config.) Fig 2.2 Configuration Tool Initialization Window (Serial Config.) Hardwired Internet Connectivity Wizard (WIZnet, Inc.) - Page 12 EG-SR-7100A(listen OK, connect fail etc.) through terminal. If not, it’s not need to check. (C) Board List Display all EG-SR-7100A in the subnet as MAC address when click “Search” button. (D) Local IP/Port EG-SR-7100A’s IP address and Port number for connection (E) Subnet EG-SR-7100A’s Subnet mask...
- Page 13 (G) Server IP/Port When the mode of EG-SR7100A is “Client mode” or “Mixed mode”, you should set the “Server IP”. EG-SR-7100A attempts to connect this IP address. (H) Enable DHCP Mode Set this option to use DHCP mode. First check ‘Enable DHCP mode’ and push ‘Setting’...
- Page 14 1. The host connects to the EG-SR-7100A which is configured as TCP Server Mode. 2. As the connection is established, data can be transmitted in both directions - from the host to the EG-SR-7100A, and from the EG-SR-7100A to the host. TCP client mode Fig 2.5 TCP Client mode To operate this mode, Local IP, Subnet, gateway address, server IP, server port number should be set.
- Page 15 In this mode, EG-SR-7100A operates as TCP Server and waits for the connction request from the peer. If there is no connection and have data to be sent to the Ethernet, EG-SR-7100A changes to the client mode and send this data to the server IP.
- Page 16 (O) Exit Close the configuration Tool program. (P) Serial Configuration Serial information of selected EG-SR-7100A is displayed. (Q) Inactivity time After the connection is established, if there is not data transmission within the time defined in Inactivity time, the connection is closed automatically.
-
Page 17: Firmware Uploading
Before upload through Ethernet, you should set the network information ☞ of EG-SR-7100A first by Configuration Tool program as shown in Fig 3.1. ⑤ When the window as shown in Fig 3.2 is displayed, select file for upload and click “Open” button... - Page 18 Fig 3.2 Open dialog box for uploading Do not upload any other file except EG-SR-7100A application firmware file. ☞ ⑥ A dialogue box titled “Processing” will be displayed as shown in Fig 3.3. Fig 3.3 Firmware uploading window ⑦ When uploading is complete, a message box with “Complete Uploading” will be displayed as shown in Fig 3.4.
-
Page 19: Using Serial Upload
3.2. Using serial upload If current firmware version is higher than ver.2.09, you should check Debug mode. Connect EG-SR-7100A serial port and computer serial port by using the serial ① cable. Make sure the position of the mode switch(JP4) is down. -
Page 20: Serial Configuration
4. Serial Configuration Warning : If current firmware version is higher than ver.2.09, you should check “Debug mode”. You can setup EG-SR-7100A’s configuration easily by sending a text configuration file through serial. The contents of configuration file have following meanings. - Page 21 Connect between EG-SR-7100A and Test PC with serial cable b. Run terminal emulator program (e.g. Hyper terminal) on Test PC c. Turn EG-SR-7100A’s power on and press ‘p’ on terminal emulator program in a few seconds immediately. (To send the configuration file using pin JP1.12 or typing ‘p’...
-
Page 22: Pin Assignment And Dimension
Link LED Output /10_LED 10 Mbps LED Output /100_LED 100 Mbps LED Output /COL_LED Collision LED Output Status High : not connected, Output Low : connected 3.3V Power Power Table 5.1 EG-SR-7100A Module Pin Functions Hardwired Internet Connectivity Wizard (WIZnet, Inc.) - Page 23 All signal level is 3.3V LVTTL A high on RESET pin about minimum 1.2 usec must be applied for proper operation. Fig 5.2 EG-SR-7100A Dimension Symbol Dimension(mm) 45.7 50.0 30.0 Table 5.2 EG-SR-7100A Dimension Hardwired Internet Connectivity Wizard (WIZnet, Inc.)
-
Page 24: Demonstration And Test
PC that has an RS-232 serial port. EG-SR-7100A & Test board Ethernet cross-over cable to connect PC's and EG-SR-7100A's LAN ports.. RS-232 cable to connect PC's COM port with EG-SR-7100A's serial data port. Software Windows operating system installed on testing PC. - Page 25 ① Make sure the position of the mode switch is normal mode. ② Connect the computer and EG-SR-7100A Test Board by using RS-232. ③ Connect the computer and EG-SR-7100A Test Board by Ethernet cross-over cable. ④ Power on the EG-SR-7100A Test Board.
- Page 26 (Data Transmission) ① Run terminal emulator program (e.g. Hyper terminal) on Test PC. ② Set the baud rate as the same value of the EG-SR-7100A. Fig 6.4 Serial Terminal Program Configuration ③ Execute another Hyperterminal and set the IP address and port number.
- Page 27 Fig 6.6 Received Data by Network Terminal Program ⑥ As the same way, type some charaters on the network Hyper terminal, and then make sure these data are shown in the serial Hyper terminal window. (Ethernet to Serial) Hardwired Internet Connectivity Wizard (WIZnet, Inc.)
-
Page 28: Reference Schematic
RIOUT R1IN R2OUT R2IN VOUT DB9 (MALE) MAX3232CSE DC JACK 5V DC 0.1u 100uF/25V LM1117(SOT223) 100uF/25V 0.1u Title EG-SR-7100A Ref . Circuit Size Document Number <Doc> Date: Wednesday , Nov ember 19, 2003 Sheet Hardwired Internet Connectivity Wizard (WIZnet, Inc.) - Page 29 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: WIZnet EG-SR-7100A EG-SR-7100A-EVB...
