If the patient data has already been entered or retrieved before the measurement in the
plusoptiX S12C or S16 model, the screening report is automatically saved to a SD card as a
PDF file at the end of every successful measurement. If you see the status message "Try
again", the screening report must be saved manually.
To be able to allocate these screening reports to individual patients, the entered patient
information can be found in the file names. In addition to the entered data, a date and time
stamp and the measurement result are added.
PDF file name:
Last name_FirstName-YYYYMMDD-HHMMSS-refer.pdf
Note:
If a patient ID has been entered in the Plusoptix Vision Screener instead of or as
well as the patient name, this patient ID will be visible in the file name instead of
the patient name
Attention:
The screening report is not stored in the internal patient database, but on the
connected SD card (plusoptiX 12) or USB stick (plusoptiX 16). It will not be
possible to retrieve screening reports in the internal patient database at a later
stage. If the device has been connected to your EMR software via the device's
CSV interface, it will be sent automatically to your EMR software if this selection
has been enabled in the settings. In this case, it is not necessary to insert a SD
card for transferring the PDF file with the "plusoptiX S12" model.
Saving the screening report takes a few seconds and depends on the storage
medium. If the SD card or USB stick is removed too soon or the URL is accessed
too soon, the PDF file will not be saved.
If the SD card or USB stick is removed too soon, it must be plugged back into the
Plusoptix Vision Screener to save the screening report to the SD card or USB
stick. The URL must be called up again if it is accessed too soon the first time.

2.2 Adding an individual infographic

An infographics is found on the lower edge of the screening report. You can design this as
you wish. Create your graphic in png format with a size of 2200 x 570 pixels (w x h) and call
your graphic "info". Copy your graphic into the main directory of a USB stick. As soon as you
connect the USB stick to the operational Plusoptix Vision Screener your graphic will be
uploaded automatically. You can find a sample graphic with the correct measurements for
the information column in the download area on our homepage (www.plusoptix.com).
