Specifications

OcuSync 2.0
Operation Frequency Range
Max Transmission Distance
(Unobstructed, free of interference)
Transmitter Power (EIRP)
Wi-Fi
Protocol
Operation Frequency Range
Transmitter Power (EIRP)
Bluetooth
Protocol
Operation Frequency Range
Transmitter Power (EIRP)
General
Battery
Charge Type
Rated Power
Storage Capacity
Charge Time
Working Time
Video Output Port
Power Supply Current/ Voltage
(USB-A port)
Operation Temperature Range
Storage Temperature Range
2.400-2.4835 GHz; 5.725-5.850 GHz*
2.400-2.4835 GHz:
8 km (FCC); 4 km (CE); 4 km (SRRC); 4 km (MIC)
5.725-5.850 GHz:
8 km (FCC) : 2 km (CE) : 5 km (SRRC)
2.400-2.4835 GHz:
25.5 dBm (FCC); 18.5 dBm (CE); 19 dBm (SRRC);
18.5 dBm (MIC)
5.725-5.850 GHz:
25.5 dBm (FCC); 12.5 dBm (CE); 18.5 dBm (SRRC)
Wi-Fi Direct, Wi-Fi Display, 802.11a/g/n/ac
Wi-Fi with 2×2 MIMO is supported
2.400-2.4835 GHz; 5.150-5.250 GHz*;
5.725-5.850 GHz*
2.400-2.4835 GHz:
21.5 dBm (FCC); 18.5 dBm (CE);
18.5 dBm (SRRC); 20.5 dBm (MIC)
5.150-5.250 GHz:
19 dBm (FCC); 19 dBm (CE);
19 dBm (SRRC); 19dBm (MIC)
5.725-5.850 GHz:
21 dBm (FCC); 13 dBm (CE); 21 dBm (SRRC)
Bluetooth 4.2
2.400-2.4835 GHz
4 dBm (FCC); 4 dBm (CE)
4 dBm (SRRC); 4 dBm (MIC)
18650 Li-ion (5000 mAh @ 7.2 V)
Supports USB power adapters rated 12 V/2 V
15 W
Rom: 16 GB + scalable (microSD**)
2 hours (Using a USB power adapter rated 12 V/2 V)
2.5 hours
HDMI Port
5 V/ 2 A
4° to 104° F (-20° to 40° C)
Less than one month: -22° to 140° F (-30° to 60° C)
One month to three months: -22° to 113° F (-30° to 45° C)
Three months to six months: -22° to 95° F (-30° to 35° C)
More than six months: -22° to 77° F (-30° to 25° C)
©
