Preparing the Smart Controller

Charging the Battery

There are two built-in 2500 mAh Li-ion batteries in the remote controller. Please charge the remote
controller using the USB-C port.
Charging Time: 2 hours (using a standard USB power adapter)
Power Outlet USB Power Adapter
100 ~ 240 V
Please use a DJI offical USB power adapter to charge the remote controller. If not, a USB
power adapter certified FCC/CE rated 12 V/2 A is recommended.
The battery will deplete when stored for an extended period of time. Please recharge the
battery at least once every three months to prevent over discharging.

Attaching the Control Sticks

Two pairs of control sticks are included in the packaging for the Smart Controller. One pair is stored
in the sticks storage slot on the back of the remote controller. Follow the steps below to attach the
control sticks stored in the sticks storage slot to the remote controller.
Lift the antennas
©
6
2019 DJI All Rights Reserved.
USB-C Cable
Remove the control sticks Rotate to attach the
control sticks
