Product Profile

Introduction

The DJI Smart Controller features OCUSYNC™ 2.0 technology and is compatible with aircraft which
support OcuSync 2.0. With a wide range of function buttons, the remote controller can perform a variety
of tasks and control the aircraft within a maximum range of 8 km. Dual transmission frequency support
makes HD video downlink stable and reliable.
Ultra-bright Screen: The built-in 5.5 inch screen boasts a high brightness of 1000 cd/m² and a resolution
of 1920×1080 pixels.
Multiple Connections: The Smart Controller supports Wi-Fi and Bluetooth connections.
Video and Audio Management: The Smart Controller has a built-in microphone and speaker, and is
capable of displaying 4K videos at 60 fps in H.264 and 2.3K videos at 60 fps in H.265 formats. In
addition, the videos can be displayed on an external monitor by using the HDMI port.
Extended Storage Capability: The Smart Controller's storage capability can be increased by using a
microSD card. This allows users to store more images and videos and makes it easier to export them to
a computer.
Reliable in More Environments: The Smart Controller can operate normally within a wide temperature
range from -4° F (20° C) to 104° F (40° C).
DJI GO Share: The brand new DJI GO Share function enable users to transfer images and videos to
smart devices after they have been downloaded from playback in DJI GO™ 4.
Maximum flight time was tested in windless conditions at a consistent speed of 15.5 mph (25
kph) using the MAVIC
Refer to Specifications to check compatible aircrafts models.
To comply with local regulations, the 5.8 GHz frequency is not available in some countries
and regions.
4K/60fps is supported for non HDR 10 bit videos. When selecting HDR 10 bit videos, only
4k/30fps is available.
2. This value should be taken for reference only.
