4. Flight
The default Stick Mode is Mode 2. In Mode 2, the left stick controls the aircraft's
altitude and heading, while the right stick controls forward, backward, and left and
right movements.
Left Stick
Turn Left
Takeoff
Push the left stick up
slowly to takeoff.
Landing
Pull the left stick down slowly until you touch the ground. Hold the left
stick down for a few seconds to stop the motors.

Specifications

Operating Frequencies
Max Transmission Distance
(Unobstructed, free of interference)
Operating Temperature Range
Built-in Battery
Transmitter Power (EIRP)
Operating Voltage
Supported Mobile Device Size
Up
Down
Turn Right
The Combination Stick Command (CSC)
can be used to start or stop the motors.
2.412-2.462 GHz, 5.745-5.825 GHz
2.4 GHz: 1.2 mi (2 km, FCC),
0.31 mi (0.5 km, CE), 0.31 mi (0.5 km, SRRC)
5.8 GHz: 1.2 mi (2 km, FCC),
0.19 mi (0.3 km, CE),0.75 mi (1.2 km, SRRC)
32° - 104° F (0° - 40° C)
2970 mAh
2.4 GHz: 26 dbm (FCC), 18 dBm (CE),
18 dBm (SRRC)
5.8 GHz: 28 dbm (FCC), 14 dBm (CE),
26 dBm (SRRC)
950 mA @3.7 V
Thickness supported: 6.5 mm-8.5 mm
Max length: 160 mm
Right Stick
Backward
Left
Forward
Right
