Summary of Contents for dji RC-N3
- Page 1 User Manual v1.0 2024.09...
- Page 2 This document is copyrighted by DJI with all rights reserved. Unless otherwise authorized by DJI, you are not eligible to use or allow others to use the document or any part of the document by reproducing, transferring or selling the document. Only refer to this document and the content thereof as instructions to operate DJI UAVs.
-
Page 3: Using This Manual
Important Hints and Tips Downloading the DJI Fly App Make sure to use DJI Fly with this product. Scan the QR code to download the latest version. • To check the Android and iOS operating system versions supported by DJI Fly, visit https://www.dji.com/downloads/djiapp/dji-fly. -
Page 4: Table Of Contents
DJI RC-N3 User Manual Contents Using this Manual Legend Downloading the DJI Fly App Downloading DJI Assistant 2 Preparing the Remote Controller Linking the Remote Controller Overview Operations Powering On/Off Charging the Battery Controlling the Aircraft Controlling the Gimbal and Camera... -
Page 5: Preparing The Remote Controller
DJI RC-N3 User Manual Preparing the Remote Controller 1. Remove the control sticks from the storage slots and mount them on the remote controller. 2. Pull out the mobile device holder. Choose the appropriate remote controller cable based on the port type of your mobile device (the cable with a USB-C connector is connected by default). -
Page 6: Linking The Remote Controller
• You can also start linking by following the method below. In the home screen of DJI Fly, tap Connection Guide, select aircraft model, and then select Connect with RC Only. © 2024 DJI All Rights Reserved. -
Page 7: Overview
DJI RC-N3 User Manual Overview 1. Power Button 8. Remote Controller Cable 2. Flight Mode Switch 9. Mobile Device Holder 3. Flight Pause/Return to Home (RTH) 10. Antennas Button 11. USB-C Port 4. Battery Level LEDs 12. Control Stick Storage Slots 5. -
Page 8: Operations
DJI RC-N3 User Manual Operations 4.1 Powering On/Off Press the power button once to check the current battery level. Press, then press and hold to power the remote controller on or off. 4.2 Charging the Battery Connect the charger to the USB-C port on the remote controller. - Page 9 DJI RC-N3 User Manual Mode 1 Mode 2 Mode 3 The default control mode of the remote controller is Mode 2. In this manual, Mode 2 is used as an example to illustrate how to use the control sticks. ©...
-
Page 10: Controlling The Gimbal And Camera
DJI RC-N3 User Manual Remote Controller Aircraft Operation (Mode 2) Throttle Stick • Push the stick up to ascend and down to descend. • The more the stick is pushed away from the center, the faster the aircraft changes elevation. -
Page 11: Flight Mode Switch
DJI RC-N3 User Manual 1. Gimbal Dial: Control the tilt of the gimbal. 2. Customizable Button: Press once to recenter the gimbal or point the gimbal downward by default. 3. Shutter/Record Button: Press once to take a photo or to start or stop recording. -
Page 12: Customizable Button
DJI RC-N3 User Manual 4.7 Customizable Button Press the customizable button to recenter the gimbal or point the gimbal downward by default. To set the function, go to camera view in DJI Fly, and tap > Control > Button Customization. -
Page 13: Battery Level Leds
DJI RC-N3 User Manual Battery Level LEDs Blinking Pattern Battery Level 76-100% 51-75% 26-50% 0-25% © 2024 DJI All Rights Reserved. -
Page 14: Remote Controller Alert
There will be an alert if the remote controller is not used for a period while it is powered on but is not connected to the aircraft or the DJI Fly app on the mobile device. The remote controller will automatically power off after the alert stops. Move the control sticks or press any button to cancel the alert. -
Page 15: Optimal Transmission Zone
Otherwise, the remote controller will experience interference. • A prompt will be displayed in DJI Fly if the transmission signal is weak during flight. Adjust the remote controller orientation according to the attitude indicator display to make sure that the aircraft is in the optimal transmission range. -
Page 16: Appendix
When using the remote controller, connect the aircraft and remote controller, and run DJI Fly. You will be notified if a new firmware update is available. Follow the on-screen instructions to start the update. Note that you cannot update the firmware if the remote ©... -
Page 17: Aftersales Information
1. Power on the device. Connect the device to a computer with a USB-C cable. 2. Launch DJI Assistant 2 (Consumer Drones Series) and log in with your DJI account. 3. Select the device and click Firmware Update on the left side of the screen. - Page 18 This content is subject to change without notice. Download the latest version from https://www.dji.com/downloads/products/rc-n3 If you have any questions about this document, please contact DJI by sending a message to DocSupport@dji.com. DJI is a trademark of DJI. Copyright © 2024 DJI All Rights Reserved.
