Specifications - dji Remote Controller C2 User Manual

4. Flight
The default Stick Mode is Mode 2. In Mode 2, the left stick controls the aircraft's
altitude and heading, while the right stick controls forward, backward, and left and right
movements.
Left Stick
Turn Left
The Combination Stick Command
(CSC) can be used to start or stop the
motors.
Takeoff
Push the left stick up slowly to
takeoff.

Specifications

Operating Frequencies
Max Transmission Distance
(unobstructed, free of interference)
Operating Temperature Range
Built-in Battery
Operating Voltage
Supported Mobile Device Size
Up
Down
Turn Right
2.412-2.462 GHz; 5.745-5.825 GHz
2.4 GHz: 1.2 mi (2 km, FCC); 0.31 mi (0.5 km, CE);
0.31 mi (0.5 km, SRCC)
5.8 GHz: 1.2 mi (2 km, FCC); 0.19 mi (0.3 km, CE);
0.75 mi (1.2 km, SRCC)
32° - 104℉ (0° - 40℃)
2970mAh
950 mA @3.7 V
Thickness supported: 6.5mm-8.5mm;
Max length: 160mm
Right Stick
Left
Landing
Pull the left stick down slowly until you
touch the ground. Hold the left stick down
for a few seconds to stop the motors.
Forward
Backward
Right
