Database Results Page - PLUSOPTIX S12C Short Manual

4 "Database" results page (only plusoptiX S12C and S16)
Every successful measurement is automatically documented in the database in chronological
order. Green entries indicate "Pass" results. Red entries indicate "Refer" results. Inconclusive
measurements are shown in Yellow.
Documenting the
measurement results
After a measurement, the measurement values can be saved as a screening report and
printed as a label. Touch the printer (1) button in the navigation bar of a results page to
assign patient data, and to send the print job via the infrared interface and save a screening
report on the SD card (plusoptiX 12) / USB stick (plusoptiX 16). For more information about
the documentation of measurement results, please see supplementary short manual 5 and 6.
Attention:
All print jobs in print spooler are deleted once device is switched off or switches
off for power saving automatically. Screening reports saved to a SD-card / USB
stick are not deleted when device is switched off or switches off for power saving.
Figure 4: "Database" results page
1)
Seite 6 von 7
