Performing The Next Measurement - PLUSOPTIX S12C Short Manual

5 Performing the next measurement

Attention:
Following an anonymous measurement, a screening report is not saved
automatically. As soon as you return to the home page without previously saving,
the screening report can no longer be saved and / or printed.
The measurement values, on the other hand, are saved under a consecutive
number when you take an anonymous measurement. This is shown in the header. If
you take a note of this consecutive number, you can access the measurement
values in the database at a later point in time and print the label.
After a successful measurement ("Refer" / "Pass"), you can:
Return to the home page by pressing the trigger. Previously entered or selected
patient data is discarded.
This is only possible within the software version CAD. In the software version
PAD, you can only return to the homepage by touching the red "X" button".
Return to the home page by touching the red "X" button". Previously entered or
selected patient data is discarded.
After an inconclusive measurement ("Refer or Try again" / "Try again"), you can:
Measure the same patient again in the pre-selected age group by pressing the
GO button or the trigger.
Return to the home page by touching the red "X" button". Previously entered or
selected patient data is discarded.
Attention:
If you receive the "Refer or Try again" screening result three times in a row and the
surrounding conditions for the measurement are correct, the child must be referred
for a further examination by an ophthalmologist.
Attention:
If the patient data was entered, retrieved or imported from the EMR software
before the measurement, the measurement values are saved automatically. If you
see the status message "Try again", the screening report must be saved manually.
Seite 7 von 7
