Operating The Machine - LELY Splendimo Triplo 801 Operator's Manual

5 OPERATING THE MACHINE

!
Operate the machine with a PTO rpm of 1,000.
During use of the machine the operator can lower or raise
either machine using the control box.
Setting the switch to middle position will control the
cylinders on both mowers. Switching it to either side controls
the cylinder on one side (see picture).
5.1 From working position to transport position
• Switch off PTO power and wait until everything has come
to a stop.
• Fully lift all the mowers and close the ball valves on each
mower cilinder.
• Activate the frame cylinders until the mowers rest on the
frame supports.
• Close the ball valves on the frame cylinders.
6 STORING THE MACHINE
• Raise the frame and place the supports (3x) underneath the
frame.
• Lower the frame, lower the mowers and disconnect the
frame from the tractor.
• The (rear)machine can eventually be stored in transport
position using the supports. In that case be sure that the
machine is placed on a stable horizontal surface.
Also make sure that all the ball valves (4x) are all closed
!
before disconnecting the frame from the tractor.
9
