- Page 1 O P E R A T O R ’ S M A N U A L SPLENDIMO TRIPLO 801 (C) E-HE.013. 0301...
- Page 3 Ehe013-a ® SPLENDIMO is a registered trademark. The right of exclusive use belongs to the companies of the Lely organisation. ©2001. All rights reserved. Nothing of this publication may be reproduced and/or published by printing, photocopying, microfilm or any other way without the prior written permission of LELY INDUSTRIES N.V.
-
Page 5: Table Of Contents
Alterations to the rear mowers are ..............5 2. SAFETY INSTRUCTIONS ...................6 3. ASSEMBLING THE MOWERS TO THE TRIPLO FRAME ........7 4. OPERATING THE SPLENDIMO TRIPLO 801 ............8 From transport position to working position ...........8 Mowing height adjustment ................8 5 OPERATING THE MACHINE ..................9 From working position to transport position ...........9... -
Page 7: Introduction
1 INTRODUCTION The SPLENDIMO TRIPLO 801 is built around three (almost) standard SPLENDIMO 280 F/FC mowers. These F/FC machines have only slight alterations allowing the customer to replace the machines for new standard machines after they have outlived their economic lifetime or after extensive damage. -
Page 8: Safety Instructions
2 SAFETY INSTRUCTIONS In addition to the safety instructions in the F/FC manual. • Although the TRIPLO frame is supplied with rear lights, apply extra lights, flashing lights or safety signs if local legislation requires this. • Make sure that there is enough weight on the front axle of the tractor to ensure a safe and proper response when steering and accelerating. -
Page 9: Assembling The Mowers To The Triplo Frame
3 ASSEMBLING THE MOWERS TO THE TRIPLO FRAME First make sure that the alterations to the mowers (as mentioned earlier) have been done. • Attach the front mower to the front of the tractor as this will double as a counterweight for the rear assembly. •... -
Page 10: Operating The Splendimo Triplo 801
4 OPERATING THE SPLENDIMO TRIPLO 801 In addition to the F/FC manual. 4.1 From transport position to working position Make sure that there is enough room to lower the machine and that there is no one standing in this “Danger-zone” •... -
Page 11: Operating The Machine
5 OPERATING THE MACHINE Operate the machine with a PTO rpm of 1,000. During use of the machine the operator can lower or raise either machine using the control box. Setting the switch to middle position will control the cylinders on both mowers. Switching it to either side controls the cylinder on one side (see picture). -
Page 12: Maintenance
7 MAINTENANCE In addition to the maintenance instructions in the F/FC manual (Chapter 7 “Maintenance”). 7.1 Lubrication For additional information regarding the individual mo- wer lubrication specifications, see chapter 7 “Maintenan- ce” of the Splendimo F/FC operator’s manual. • The TRIPLO frame incorporates three extra PTO-shafts that are to be greased every 8 hours •...
