IntesisBox ASCII Server - KNX

4.7 Files

LinkBoxEIB saves IntesisBox configuration in the following files inside the project folder:
PROJECT.INI
ASCII.INI
ASCII.DAT
ASCII.LBOX
It is strongly recommended to back up the project folder containing these files in external
media, once the installation process is finished. This way you will be able to do future
configuration changes in case of reinstallation of LinkBoxEIB due, for example, to a failure
of the hard disk in the PC where LinkBoxEIB was previously installed.
The configuration cannot be downloaded from IntesisBox to LinkBoxEIB, only can
be uploaded; the upload file ASCII.LBOX does not contain all the integration
information, as for example the signals description.
© Intesis Software S.L.U. - All rights reserved
This information is subject to change without notice
IntesisBox ® is a registered trademark of Intesis Software SLU
.ini file containing general information referent to the project
.ini file containing the information referent to the connection
window and other special adjustments
Text file (tab separated values) with the signals information
(signals list). This file can be edited (with Excel for example) to
change the configuration quicker and easier. Later on, when
selecting Configuration -> IntesisBox in LinkBoxEIB, if the changes
have been made respecting the correct format, all the changes in
the configuration done from Excel can be seen in the signals list.
Binary file created from the information in the files described
above. This is the file really uploaded to IntesisBox.
