4.8 Files

LinkBoxBacnet saves the IntesisBox configuration in the following files inside the project
folder:
PROJECT.INI .ini file containing general information referent to the project
ASCI-INT.INI .ini file containing the information referent to the connection window and
other special adjustments
ASCI-INT.DAT Text file (tab separated values) with the signals information (signals list).
This file can be edited (with Excel for example) to change the
configuration quicker and easier. Later on, when selecting Configuration -
> IntesisBox in LinkBoxBacnet, if the changes have been made respecting
the correct format, all the changes in the configuration done from Excel
can be seen in the signals list.
ASCI-INT.LBOX Binary file created from the information in the files described above. This
is the file uploaded to the gateway.
It is strongly recommended to back up the project folder containing these files in external
media, once the installation process is finished. This way you will be able to do future
configuration changes in case of reinstallation of LinkBoxBacnet due, for example, to a
failure of the hard disk in the PC where LinkBoxBacnet was previously installed.
The configuration cannot be downloaded from the gateway to LinkBoxBacnet, only
can be uploaded; the upload file ASCI-INT.LBOX does not contain all the
integration information, as for example the signals description.

4.9 Functionality considerations

IntesisBox returns some useful information about internal parameters in response to an
INFO command:
Referent to IntesisBox:
- Firmware version and serial number.
- Protocols versions.
Referent to BACnet side:
- IP address configured.
- NetMask configured.
- Default Gateway configured.
* See Release notes of the latest firmware version for up to date information on IntesisBox
ASCII - BACnet IP client gateway and LinkBoxBacnet functionality.
